Запчасти Case IH JX65 (1.92.0[54]) - CAB - NUMBER PLATE MOUNT (10) - OPERATORS PLATFORM/CAB

1

86400906

WARNING TRIANGLE

1шт.

2

5148516

BRACKET

1шт.

3

5148517

SUPPORT

1шт.

4

5089433

PAD

1шт.

5

5092999

BRACKET

1шт.

6

16043221

BOLT,Hex, M8 x 16mm, Cl 8.8, Full Thd

4шт.

7

10519601

WASHER,8.15mm ID x 17mm OD x 2mm Thk

8шт.

8

10519401

WASHER,6.4mm ID x 11.95mm OD x 1.6mm Thk

2шт.

9

12574211

NUT,M6 x 1, Cl 8

2шт.

10

16104111

NUT,Prevailing Torque, M8, 1.25 Pitch, 10.6mm High, Cl 08, ZND

4шт.
