Запчасти Case IH FARMALL 95C (90.100.AF) - VAR - 334216 - HOOD, PROTECTION PLATE (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

47397982

GUARD

1шт.

2

11193874

BELLEVILLE WASHER,M8 Bolt Size x 16mm OD x 1.4mm Thk

7шт.

3

16281924

FLANGE BOLT,Hvy Hex, M8 x 14mm, Cl 8.8, Full Thd

M8 x 14 Full 8.8 DAC

1шт.

4

16043424

SCREW,Hex, M8 x 1.25 x 20mm, Cl 8.8, Full Thd

6шт.

5

84573392

GUARD

1шт.

6

84573887

BRACKET

2шт.

7

47375716

GUARD

1шт.

8

16043224

BOLT,Hex, M8 x 16mm, Cl 8.8

1шт.

9

10902124

SCREW,Hex, M6 x 14mm, Cl 8.8

2шт.

10

11194774

BELLEVILLE WASHER,M6 Bolt Size x 18mm OD x 1.4mm Thk

2шт.
