(1.82.7/06B) - THREE CONTROL VALVES (BOSCH) - PARTS - D6083

Запчасти Case IH FARMALL 85U (1.82.7/06B) - THREE CONTROL VALVES (BOSCH) - PARTS - D6083 (07) - HYDRAULIC SYSTEM

Схема запчастей Case IH FARMALL 85U - (1.82.7/06B) - THREE CONTROL VALVES (BOSCH) - PARTS - D6083 (07) - HYDRAULIC SYSTEM
3
4
1
6
2
1.82.7/05e
home
1.82.7/05f
5
7
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87597110

CONTROL VALVE

1шт.

2

87701610

HYD VALVE SECTION

Inlet

1шт.

3

87597107

DISTRIBUTOR

Directional

2шт.

4

87597108

DISTRIBUTOR

Directional

1шт.

5

87726326

HYD VALVE SECTION

End Plate

1шт.

6

5195168

TIE-ROD,M8

3шт.

7

5195169

NUT,M8

3шт.

Выбрано товаров: 7
