Запчасти Case IH FARMALL 85U (1.19.1) - DRY AIR CLEANER (02) - ENGINE EQUIPMENT

Схема запчастей Case IH FARMALL 85U - (1.19.1) - DRY AIR CLEANER (02) - ENGINE EQUIPMENT
29
22
18
15
16
19
20
23
13
3
21
2
20
1
4
9
12
24
27
25
28
11
home
1.19.1/a
17
8
18
26
7
6
5
10
21
14

Артикул

Название

Примечание

Количество

1

84308764

HEAT EXCHANGER

20 Plates, JXU 75 / 75U, JXU 85 / 85U, JXU 95 / 95U

1шт.

1

84308760

HEAT EXCHANGER

28 Plates, JXU 105 / 105U

1шт.

2

87644002

HOSE CLIP,57-65mm

3шт.

2

87707423

HOSE CLIP,40-50mm

1шт.

3

87379382

RIGID TUBE,57 mm OD x 255, 28.2 mm L

RH,from intercooler to turbocharger

1шт.

4

87379381

RIGID TUBE,57 mm OD x 255, 51.1 mm L

LH,from intercooler to inlet manifold

1шт.

5

87644234

HOSE CLIP

3шт.

5

87644233

HOSE CLIP

1шт.

6

87573503

SUPPORT

RH

1шт.

7

87573504

SUPPORT

LH

1шт.

8

87561569

BRACKET

1шт.

9

87571010

BRACKET

JXU 75 / 75U, JXU 85 / 85U, JXU 95 / 95U

1шт.

9

87338612

BRACKET

JXU 105 / 105U

1шт.

10

87561570

SUPPORT

1шт.

11

87347224

FILTER ASSY

ASSY

1шт.

12

16043224

BOLT,Hex, M8 x 16mm, Cl 8.8

4шт.

13

11194074

BELLEVILLE WASHER,M8 Bolt Size x 16mm OD x 1.9mm Thk

4шт.

14

10902324

BOLT,Hex, M6 x 18mm, Cl 8.8, Full Thd

4шт.

15

11194674

BELLEVILLE WASHER,M6 Bolt Size x 15mm OD x 1mm Thk

4шт.

16

87348023

RIGID TUBE

1шт.

17

87392668

RIGID TUBE,59.4 - 88.1 mm OD x 691.2, 159.4 mm L

1шт.

18

82980514

CLAMP,32mm - 50mm

For hose 87678199

2шт.

18

82039345

HOSE CLAMP,25mm - 40mm, Worm Gear

For hose 5183408

2шт.

19

13000890

HOSE CLAMP,50mm - 70mm, Worm Gear

1шт.

20

13000490

HOSE CLAMP,20mm - 32mm, Worm Gear

2шт.

21

11193874

BELLEVILLE WASHER,M8 Bolt Size x 16mm OD x 1.4mm Thk

12шт.

22

16043221

BOLT,Hex, M8 x 16mm, Cl 8.8, Full Thd

4шт.

23

16043824

SCREW,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd, DAC

4шт.

24

47131590

SPACER,8.5mm ID x 26mm OD x 10mm Thk

4шт.

25

47131603

PAD,14mm ID x 26mm OD x 8mm Thk

4шт.

26

87546353

ADAPTER

1шт.

VAR.331199 Exhaust Aspirated Dry Air Clear

1шт.

27

5183408

HOSE,32.00 mm ID x 750.00 mm

L/CAB

1шт.

VAR.331199 Exhaust Aspirated Dry Air Clear

1шт.

27

87678199

AIR HOSE,32.00 mm ID, 37.00 mm OD x 1250.00 mm

W/Cab

1шт.

VAR.331199 Exhaust Aspirated Dry Air Clear

1шт.

28

87347229

PROTECTION CAP,84mm OD x 68mm L

1шт.

29

87747295

HEX SOC SCREW,Btn Hd, M8 x 1.25 x 12mm, Cl 12.9

4шт.
