Запчасти Case IH FARMALL 85C (1.92.26/03) - FRONT AXLE WITH EL.HYDR. DIFF. LOCK (40 KM/H) FOR FRONT HPL - PTO CONTROL (VAR.330848-331848-332848-333848) (10) - OPERATORS PLATFORM/CAB

1

11087674

WASHER,4mm, CST DAC

D=4

1шт.

2

13789531

SCREW,M6 x 20mm, Cl 10.9, Chamfer Pt

M6 x 20

1шт.

3

47133756

ROD

1шт.

4

5172532

CUP

1шт.

5

5168870

SPRING

1шт.

6

47136071

KNOB

1шт.

7

14162074

LOCK PIN,M3 x 22, Slotted

1шт.

8

47133751

LEVER

1шт.

9

10902224

SCREW,Hex, M6 x 16mm, Cl 8.8, Full Thd

2шт.

10

47133739

SUPPORT

1шт.

11

47133741

ROLLER BEARING,14" OD x 15"

1шт.

12

47133759

PIN

1шт.

13

10902824

BOLT,Hex, M6 x 30mm, Cl 8.8

1шт.

14

11193274

BELLEVILLE WASHER,M6 Bolt Size x 15mm OD x 1.2mm Thk

1шт.

15

15896221

NUT,Hex, M6, 5.20mm High, Cl 10

1шт.

16

47127746

PIN

1шт.

17

47128052

SPACER

1шт.

18

11181674

BELLEVILLE WASHER,M5 Bolt Size x 15mm OD x 1mm Thk

1шт.

19

47134049

SPRING

1шт.

20

47133754

RUBBER PAD

2шт.

21

11193270

M6 x 16 x 1.2

1шт.
