Запчасти Case IH FARMALL 85C (1.80.1/05[01]) - POWER TAKE-OFF (540-1000 RPM) - NA - COVER, SHAFTS AND GEARS (VAR.330808-331808) (07) - HYDRAULIC SYSTEM

Схема запчастей Case IH FARMALL 85C - (1.80.1/05[01]) - POWER TAKE-OFF (540-1000 RPM) - NA - COVER, SHAFTS AND GEARS (VAR.330808-331808) (07) - HYDRAULIC SYSTEM
24
5
32
14
15
21
8
4
6
home
13
10
36
27
35
16
9
23
22
8
11
7
28
19
34
3
29
2
33
18
1
20
30
17
12
25
26
31

Артикул

Название

Примечание

Количество

1

5187934

COVER

1шт.

2

5177640

SHAFT

1шт.

3

44012300

PIN,14mm OD x 37mm L

M12 x 37

3шт.

4

16105021

LOCK NUT,M12 x 1.25, Cl 10

3шт.

5

5185602

SHAFT,540 rpm, 6 Teeth

540 RPM (6 Teeth)

1шт.

5

5185601

SHAFT,1000 rpm, 21 Teeth

1шт.

6

47123688

SHAFT

1шт.

7

5168181

THRUST WASHER,35.1mm ID x 50mm OD x 4mm Thk

1шт.

8

5124668

BUSHING,38mm ID x 46mm OD x 28mm L

2шт.

9

47123681

GEAR

540 RPM

1шт.

10

5130551

SLEEVE,70mm ID x 100mm OD x 20mm L

1шт.

11

5130550

PINION,28T / 12T

1шт.

12

47123683

GEAR

1000 RPM

1шт.

13

20045200

BALL BEARING,35mm ID x 80mm OD x 21mm

35 x 80 x 21

1шт.

14

5180676

PIN,12mm Od x 191.5mm L

1шт.

15

5103230

O-RING,2.62mm Thk x 11.91mm ID

1шт.

16

14466080

O-RING,0.139" Thk x 3.984" ID, -242, Cl 5, 75 Duro

1шт.

17

47133662

COVER

1шт.

18

370026

SNAP RING,M100 x 3mm Thk, Internal

1шт.

19

5173210

NEEDLE BEARING,Needle, 43mm ID x 58mm OD x 22mm W

43 x 58 x 22

1шт.

20

5142178

SNAP RING,1.5mm Thk

1шт.

21

84078050

SNAP RING,M22, Int

1шт.

22

5168238

BALL BEARING,40mm ID x 90mm OD x 23mm W

40 x 90 x 23

1шт.

23

11068876

SNAP RING,M40, Ext

1шт.

24

5124606

SEAL,50mm ID x 65mm OD x 8mm Thk

50 x 65 x 8

1шт.

25

5168238

BALL BEARING,40mm ID x 90mm OD x 23mm W

40 x 90 x 23

1шт.

26

47131175

BRAKE DISC,14mm ID x 70mm OD x 4mm Thk

1шт.

27

47130774

PIN,13.5mm OD x 22mm L

1шт.

28

47132279

SPRING,Compression, 33mm OD x 29mm L

1шт.

29

13543624

STUD,M8 x 1.25 x 46mm L, 22 Thd, Cl 8.8

6шт.

30

16100811

NUT,Hex, M8, 6.80mm, Cl 8, ZND

6шт.

31

5124675

THRUST WASHER,38.1mm ID x 56mm OD x 4mm Thk

1шт.

32

5149398

SPRING,Compression, 23mm OD x 48mm L

1шт.

33

14306324

HEX SOC SCREW,M8 x 1.25 x 20mm, Cl 8.8, Full Thd

4шт.

34

10569374

LOCK WASHER,M8

4шт.

35

87341678

THRUST WASHER,38.1mm ID x 58mm OD x 2.5mm Thk

1шт.

36

87302766

DISC,38.1mm ID x 152mm OD x 1.5mm Thk

1шт.

Выбрано товаров: 37
