(1.40.3/07[02]) - 4WD FRONT AXLE NO-SPIN DIFFERENTIAL LOCK - DIFFERENTIAL (VAR.336325)

Запчасти Case IH FARMALL 80 (1.40.3/07[02]) - 4WD FRONT AXLE NO-SPIN DIFFERENTIAL LOCK - DIFFERENTIAL (VAR.336325) (04) - FRONT AXLE & STEERING

Схема запчастей Case IH FARMALL 80 - (1.40.3/07[02]) - 4WD FRONT AXLE NO-SPIN DIFFERENTIAL LOCK - DIFFERENTIAL (VAR.336325) (04) - FRONT AXLE & STEERING
5
3
5
2
5
4
5
5
5
1
5
1
5
5
5
1.40.1/06 01
home
5
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

24903450

TAPERED BEARING,60mm ID x 95mm OD x 23mm W

60 x 95 x 2

2шт.

2

5117780

DIFFERENTIAL GEAR

SPARE PART DIFFERENTIAL GEAR

1шт.

3

5117783

DIFFERENTIAL

1шт.

4

5117821

SCREW

8шт.

5

5117589

KIT

1шт.
