Запчасти Case IH FARMALL 75C (90.114.AQ[01]) - VAR - 334187, 334190, 392315 - ROPS, W/O CAB (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

47392586

ROPS

1шт.

2

5095360

PIN,17.8mm OD x 103mm L

2шт.

3

16045024

BOLT,Hex, M8 x 1.25 x 90mm, Cl 8.8

2шт.

4

12646701

WASHER,8.15mm ID x 20mm OD x 2mm Thk

2шт.

5

16104111

NUT,Prevailing Torque, M8, 1.25 Pitch, 10.6mm High, Cl 08, ZND

2шт.

6

15985234

SCREW,M18 x 1.5 x 100mm

HEX, M18 x 1.5 x 100mm

2шт.

7

14497124

WASHER,21mm ID x 37mm OD x 3mm Thk

21mm x 37mm x 3mm

2шт.

8

12575011

LOCK NUT,M18 x 1.5, Cl 8

2шт.
