Запчасти Case IH FARMALL 75C (25.100.AV[04]) - VAR - 334218, 334361 - AXLE SUPPORT, 4WD (25) - FRONT AXLE SYSTEM

1

47646589

SUPPORT

1шт.

2

47641569

PLATE

1шт.

3

16043511

SCREW

6шт.

4

84188434

WASHER,8.4mm ID x 16mm OD x 1.6mm Thk

5шт.

5

15988231

BOLT,Hex, M20 x 1.5 x 55mm, Cl 10.9, Full Thd

6шт.

6

11191879

BELLEVILLE WASHER,Belleville, 20mm ID x 38mm OD x 5.2mm Thk

8шт.

7

15989134

BOLT,Hex, M20 x 1.5 x 100mm, Cl 10.9

2шт.

8

84398609

PIN,20mm OD x 25mm L

2шт.

9

87600545

BUTTON PLUG,M17 x 11.50mm

4шт.

10

84408278

PLUG,Closing cavity

2шт.

11

81862738

PLUG,M38 x 28 x 5mm

2шт.
