(33.110.0101) - PARKING BRAKE - PARKING LOCK ON BRAKE PEDALS - NAR - L/CAB

Запчасти Case IH FARMALL 75C (33.110.0101) - PARKING BRAKE - PARKING LOCK ON BRAKE PEDALS - NAR - L/CAB (33) - BRAKES & CONTROLS

Схема запчастей Case IH FARMALL 75C - (33.110.0101) - PARKING BRAKE - PARKING LOCK ON BRAKE PEDALS - NAR - L/CAB (33) - BRAKES & CONTROLS
home
6
8
4
6
5
3
7
33.202.0401
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84290775

BRACKET

1шт.

2

11197774

BELLEVILLE WASHER,M6 Bolt Size x 12mm OD x 1.2mm Thk

1шт.

3

10902024

SCREW,Hex, M6 x 12mm, Cl 8.8

1шт.

4

84349775

LEVER

1шт.

5

47134379

BUSHING

1шт.

6

13507421

WASHER,12.2mm ID x 20mm OD x 2mm Thk

2шт.

7

84607076

WASHER

1шт.

8

84290761

SPRING

1шт.
