Запчасти Case IH FARMALL 75C (1.82.7/12[02]) - 4 REAR REMOTE VALVES FOR MDC W/HYDRAULIC DIVIDER - PIPES AND RINGS (VAR.330166) (07) - HYDRAULIC SYSTEM

Схема запчастей Case IH FARMALL 75C - (1.82.7/12[02]) - 4 REAR REMOTE VALVES FOR MDC W/HYDRAULIC DIVIDER - PIPES AND RINGS (VAR.330166) (07) - HYDRAULIC SYSTEM
2
11
1
1.82.7/a
home
pag. 1
pag. 1
pag. 1
pag. 1
1.82.7/11a
1.82.7/09a
13
10
1
6
2
3
14
15
8
1.92.82
1.92.82/02
12
5
4
7
16
9

Артикул

Название

Примечание

Количество

1

11087776

CIRCLIP,Ext., M6, BLO

4шт.

2

5172456

PIN,6mm OD x 20mm L

4шт.

3

5178183

CLEVIS

2шт.

4

5116896

LINK,19.05mm Pitch

4шт.

5

87335172

SEALING RING,19mm ID x 26mm OD x 3mm Thk

SEALRING 19 x 3.50 x 3

16шт.

6

87357854

SEALING RING,15.5mm ID x 19.5mm OD x 2mm Thk

SEALRING D19.2

2шт.

7

5178877

CLEVIS

2шт.

8

5184345

BANJO BOLT,M18 x 1.5 x 34mm

M18 x 34

1шт.

9

5186176

SEALING WASHER,15.80mm ID x 26.92mm OD x 1.50mm, Steel, Zinc

2шт.

10

5188499

RIGID TUBE

Incl.7

1шт.

11

5158364

ELBOW,90°, 7/8"-14", M22 X 1.5 ORB

1шт.

12

14438085

O-RING,19.3mm ID x 2.4mm

1шт.

13

15540424

SCREW,Hex, M12 x 1.25 x 30mm, Cl 8.8, Full Thd

3шт.

14

5179944

CONSOLE

1шт.

15

11190574

BELLEVILLE WASHER,M10 Bolt Size x 20mm OD x 2.3mm Thk

1шт.

16

15970524

BOLT,Hex, M10 x 1.25 x 20mm, Cl 8.8, Full Thd

1шт.

Выбрано товаров: 16
