(10.210.01[02]) - FUEL PUMP

Запчасти Case IH FARMALL 75A (10.210.01[02]) - FUEL PUMP (10) - ENGINE

Схема запчастей Case IH FARMALL 75A - (10.210.01[02]) - FUEL PUMP (10) - ENGINE
2
1
4
3
8
7
6
home
10.103.03 02
10.101.01 02
10.304.03 02
10.001.02 02
10.106.02
5
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

2830122

FUEL PUMP

1шт.

2830122R

REMAN-INJECTION PUMP

Reman Fuel Pump

1шт.

2830122C

CORE-INJECTION PUMP

Return Number, Fuel - For N.A. Only

1шт.

504374940C

CORE-INJECTION PUMP

Return Number, Fuel - For N.A. Only

1шт.

2

2830156

O-RING,70 Duro, M2.62 Thk

1шт.

3

504218933

BANJO BOLT

1шт.

4

504218931

FITTING

1шт.

5

17750480

SEAL,12.2mm ID x 17.8mm OD x 1.5mm Thk

2шт.

6

504197289

FITTING

1шт.

7

4894721

SEALING WASHER,12.2mm ID x 17mm OD x 1.5mm Thk

1шт.

8

16586724

SCREW,M8 x 1.25 x 40mm

M8 x 1.25 x 40

2шт.

Выбрано товаров: 11
