Запчасти Case IH FARMALL 65C (90.124.AE[02]) - BACK (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH FARMALL 65C - (90.124.AE[02]) - BACK (90) - PLATFORM, CAB, BODYWORK AND DECALS
6
90.124.ak (04)
7
1
3
5
4
55.408.bl
90.124.am (03)
90.124.an
90.151.ad (06)
2
90.124.ak (03)
3
90.124.am (02)
90.124.ad (02)
90.124.al (02)
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

47488681

DRIVER SEAT

ASSY, Fabric, Wheat

1шт.

Air Suspension, W/ Safety Switch, W/ Armrest

1шт.

See Driver Seat Components also in Section, Subsection 55.408, 90.124, 90.151

1шт.

2

84222314

SEAT SUPPORT

1шт.

3

16043434

BOLT,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd

8шт.

4

11194074

BELLEVILLE WASHER,M8 Bolt Size x 16mm OD x 1.9mm Thk

8шт.

5

15811487

CAP,13mm x 8.5mm

4шт.

6

5089481

CAP,17mm OD

4шт.

7

84255310

COVER

1шт.
