Запчасти Case IH FARMALL 50A (25.400.AM[01]) - FRONT AXLE SUPPORT, 4WD (25) - FRONT AXLE SYSTEM

Схема запчастей Case IH FARMALL 50A - (25.400.AM[01]) - FRONT AXLE SUPPORT, 4WD (25) - FRONT AXLE SYSTEM
35.220.aa 01
9
4
1
7
3
12
4
11
4
6
10
10
8
2
5
5
41.216.an 01

Артикул

Название

Примечание

Количество

1

47810717

MOUNTING PLATE

Bracket Assy Mounting

1шт.

2

10902821

SCREW,Hex, M6 x 30mm, Cl 8.8

3шт.

3

81845038

O-RING,0.5" ID x 0.07" Thk

1шт.

4

81832258

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

3шт.

5

81844851

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

2шт.

6

47671979

HOSE

Assy Delivery, Pump to Motor

1шт.

7

9992298

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

1шт.

8

10257460

SEAL,M20.3 x 26 x 1.5

Seal

2шт.

9

47671983

HOSE

Assy Motor to Tank

1шт.

10

9993141

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

2шт.

11

47671973

HOSE

Assy, Motor to Cylinder, LH Rear

1шт.

12

12646601

WASHER,6.15mm ID x 15mm OD x 1.5mm Thk

1шт.

Выбрано товаров: 12
