Артикул
Название
Примечание
Количество
1
47956121
BRACKET
1шт.
2
16100811
NUT,Hex, M8, 6.80mm, Cl 8, ZND
4шт.
3
83931520
WASHER,8.4mm ID x 17mm OD x 2mm Thk
4шт.
4
86625006
BOLT,Hex, M8 x 1 x 16mm, Cl 8.8, Full Thd
4шт.
5
47569446
INCHING VALVE
1шт.
7
10519421
WASHER,6.4mm ID x 11.95mm OD x 1.6mm Thk
1шт.
8
5180153
BRACKET
1шт.
9
5180016
BRACKET
1шт.
11
16286324
BOLT,Hex, M6 x 30mm, Cl 8.8
1шт.
13
10442090
RETAINER,26mm, Coat, P Type
1шт.
14
87015907
BOLT,M6 x 10mm, Full Thd, 8.8 PHC
1шт.
15
84605368
HYD CONNECTOR
1шт.
17
47525392
PIPE
Discharge
1шт.
18
47744879
PIPE
Supply
1шт.
19
47690199
PIPE
Load Sensing
1шт.
20
86579671
HYD CONNECTOR,11/16" - 16 ORFS x M14 x 1.5 ORB
ASSY, Incl 21 - 23
1шт.
21
NSS
NOT SOLD SEPARAT
Connector, Incl in 20
1шт.
23
86598099
O-RING,2.2mm Thk x 11.3mm ID, Cl 6
1шт.
24
86579680
HYD CONNECTOR,1"-14 ORFS x M22 x 1.5mm ORB
ASSY, Incl 25 - 27
2шт.
25
NSS
NOT SOLD SEPARAT
Connector, Incl in24
2шт.
29
86598047
PLUG,Hex Soc, M22 x 1.5, ORB
ASSY, Incl 30, 31
1шт.
30
NSS
NOT SOLD SEPARAT
Plug, Incl in 29
1шт.
31
14438085
O-RING,19.3mm ID x 2.4mm
1шт.
32
719302070
DIA KIT, TRACTOR
Load Sensing Mid Mount Valve, Incl 2 - 27, 29 - 31
1шт.
To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown
1шт.
32
719302090
DIA KIT, TRACTOR
Load Sensing Mid Mount Valve, Incl 2 - 27, 29 - 31
1шт.
To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown
1шт.
Выбрано товаров: 35
