(88.100.55[02]) - DIA KIT, WATER TEMPERATURE SENDER

Запчасти Case IH FARMALL 120C (88.100.55[02]) - DIA KIT, WATER TEMPERATURE SENDER (88) - ACCESSORIES

Схема запчастей Case IH FARMALL 120C - (88.100.55[02]) - DIA KIT, WATER TEMPERATURE SENDER (88) - ACCESSORIES
7
5
1
6
3
2
1
1
1
10.001.ad (02)
10.001.ad (01)
4
1
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87717682

SERVICE KIT

Block Heater, Incl 2 - 6

1шт.

2

12646001

WASHER,14.4mm ID x 24mm OD x 2mm Thk

1шт.

3

L11541

CABLE TIE,203.2mm L, Nylon

1шт.

4

87693858

CABLE,Heater, 820W - 120V

Block Heater Cable

1шт.

5

87693857

HEATER,820W - 120V

Heater, 120V, ASSY

1шт.

6

86050279

FLANGE NUT,M10 x 1.5, Cl 10

1шт.

7

719216250

DIA KIT, TRACTOR

Engine Water Heater, Incl 1 - 7

1шт.

Выбрано товаров: 7
