Запчасти Case IH FARMALL 120C (55.015.AA[01]) - VAR - 336839 - ELECTRONIC CONTROL UNIT, SUPPORT (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH FARMALL 120C - (55.015.AA[01]) - VAR - 336839 - ELECTRONIC CONTROL UNIT, SUPPORT (55) - ELECTRICAL SYSTEMS
3
10.310.aa
4
2
10
8
6
7
9
1
5

Артикул

Название

Примечание

Количество

1

47465459

SUPPORT

1шт.

2

84351834

BRACKET

1шт.

3

87672920

RUBBER SEAL,19mm ID x 30mm L x 3mm Thk

3шт.

4

47131590

SPACER,8.5mm ID x 26mm OD x 10mm Thk

3шт.

5

47131603

PAD,14mm ID x 26mm OD x 8mm Thk

3шт.

6

16043680

BOLT,Hex, M8 x 1.25 x 25mm, Full Thd

3шт.

7

16287134

FLANGE BOLT,Hex, M8 x 20mm, Cl 10.9

M8 X 20 FULL 10.9 DAC

4шт.

8

16286324

BOLT,Hex, M6 x 30mm, Cl 8.8

M6 X 30 8.8 DAC

6шт.

9

9804256

BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8

2шт.

10

47409807

SHIELD

1шт.

Выбрано товаров: 10
