Запчасти Case IH FARMALL 115C (35.204.BJ[10]) - VAR - 336108 – REMOTE CONTROL VALVE, PIPE (HI - LO) (35) - HYDRAULIC SYSTEMS

1

84598841

HYDRAULIC HOSE

From EDC to Ext. Cylinders

1шт.

2

82016498

HYD CONNECTOR,M22 x 1.5 DIN, 1" - 14 ORFS

ASSY, Incl 3 - 5

1шт.

3

83901443

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

Incl in 2

1шт.

4

82016732

SEAL,19.6mm ID x 24.3mm OD x 1.5mm Thk

Incl in 2

1шт.

5

NSS

NOT SOLD SEPARAT

Fitting, Incl in 2

1шт.

6

47420906

PIPE

Return EDC

1шт.

7

14457180

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

1шт.

8

44015841

BACK-UP RING,19mm ID x 20mm OD x 2.05mm Thk

1шт.

9

14305421

HEX SOC SCREW,M6 x 25mm, Cl 8.8

2шт.

10

86579694

ELBOW,90 Degree, 1"-14 ORFS x M22 x 1.5 ORB

ASSY, Incl 11 - 13

1шт.

11

9992069

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

Incl in 10

1шт.

12

86598102

O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro

Incl in 10

1шт.

13

NSS

NOT SOLD SEPARAT

Fitting, Incl in 2

1шт.
