Заказать запчасти
Запчасти Case IH FARMALL 115C (90.120.AD[20]) - VAR - 331156 - DRIVER SEAT, W/O CAB (90) - PLATFORM, CAB, BODYWORK AND DECALS
![Схема запчастей Case IH FARMALL 115C - (90.120.AD[20]) - VAR - 331156 - DRIVER SEAT, W/O CAB (90) - PLATFORM, CAB, BODYWORK AND DECALS](https://partsell.ru/storage/images/caseih/5136472.png)
4
2
4
3
5
6
6
home
90.120.ad (21)
1
5
90.120.ad (21)
№
Артикул
Название
Примечание
Количество
1
84352965
SEAT
Assy, Incl 2 - 6
1шт.
Includes Also 90.120.AD (21) and 90.120.BB
1шт.
2
84539309
BACKREST
1шт.
3
47449315
SEAT CUSHION
1шт.
Includes Operator's Presence Sensor (DOPS)
1шт.
4
47388032
KIT
Armrest Covers & Hardware
1шт.
5
84361127
SEAT BELT,73.5mm W x 1120mm L
L=1120mm
1шт.
5
84361200
SEAT BELT,51mm W x 1470mm L
L=1470mm
1шт.
6
84424659
KIT
RH and LH Armrests with Hardware
1шт.
Выбрано товаров: 9
