Запчасти Case IH FARMALL 110U (05.100.02) - INITIAL STOCKING LIST (LIST B) (05) - SERVICE & MAINTENANCE

1

504231722

DIPSTICK

on Engine

1шт.

2

5801649074

THERMOSTAT

on Engine

1шт.

3

8099174

GASKET KIT

Engine Valve Adjustment (Includes all the Cylinder Head Gaskets)

1шт.

4

8099175

GASKET KIT

Engine Overhaul (Includes all the Engine Gaskets)

1шт.

5

5801714865

SEAL

Engine Valve Cover

1шт.

6

504379050

GASKET

Crankcase Front Cover

1шт.

7

504164360

GASKET

Fuel, W/ Water Separator, on Engine

1шт.

8

504170332

MANIFOLD GASKET

Fuel, Primary, on Engine

1шт.

9

5801705579

GASKET

Intake Manifold

2шт.

10

5801752064

GASKET

Intake Manifold Spacer

1шт.

11

504235816

GASKET

Oil Filter Head

1шт.

12

504381582

GASKET

Fuel, Pre-cleaner

1шт.

13

5801477100

SENSOR

Fuel Temperature

1шт.

14

500382599

SENSOR,Temperature

Coolant

1шт.

15

5801506502

SENSOR

Water Separator on Fuel Filter

1шт.

16

504084983

PRESSURE SWITCH

Engine Oil Filter

1шт.

17

5801600537

SENSOR

Engine Camshaft Position

1шт.

18

4897242

SENSOR

Engine Crankshaft Position

1шт.

19

504381064

SENSOR

Exhaust Manifold Temperature

1шт.

20

5801382522

SENSOR

Exhaust manifold Pressure

1шт.

21

47383500

ALTERNATOR,14V, 120A, W/Pulley

1шт.

22

47514881

ALTERNATOR,14V, 200A, W/ Pulley

1шт.

23

84491465

WET BATTERY,EN D04, 12V, 800CCA/140AH

ISO only

1шт.

24

BCMD4W

WET BATTERY,D4, 12V, 1200 CCA

450CCA/140AH, US only

1шт.

25

CBCMD4W

WET BATTERY,D4, 12V, 1200 CCA

450CCA/140AH, CANADA only

1шт.

26

14144690

BULB,P21/5W, 12V, 21/5W

1шт.

27

14148090

BULB,PY21W, 12V, 21W

1шт.

28

14148190

BULB,P21W, 12V, 21W

NA only

1шт.

29

14151590

BULB,H3, 12V, 55W

1шт.

30

86616248

BULB,H1, 12V, 55W

1шт.

31

47429996

BULB,Type 886, Halogen, 12V, 50W

1шт.

32

87283179

BULB,H4, 12V, 60/55W

1шт.

33

10857790

BULB,R10W, 12V, 5W

ISO only

1шт.

34

47604628

FILLER CAP

Fuel Tank, Lockable

1шт.

35

47604632

FILLER CAP,Male, Vented_Lockable

DEF/ADBLUE™ Tank, Lockable

1шт.

36

47610925

FILLER CAP,Male, Vented, Lockable

Brake Fluid Reservoir

1шт.

37

82022744

CAP,Female, Vented, Non-Locking

Radiator Tank

1шт.

38

84206552

FILLER CAP,Male

DEF/ADBLUE™ Tank

1шт.

39

84547727

FILLER CAP,M59, Vented

Fuel Tank, not Lockable

1шт.

40

87736207

DIODE,1A, Black

Black

2шт.

41

82012388

FUSE,30A, Maxival, Green

1шт.

42

84157159

FUSE,40A, Maxi, Orange

1шт.

43

84127702

FUSE,10A, Mini, Red

1шт.

44

84127703

FUSE,15A, Mini, Blue

1шт.

45

84127704

FUSE,20A, Mini, Yellow

1шт.

46

84127705

FUSE,25A, Mini, White

1шт.

47

84152583

FUSE,7.5A, Mini, Brown

1шт.

48

84153830

FUSE,5A, Mini, Beige

1шт.

49

84326484

FUSE,3A, Mini, Violet

1шт.

50

84416717

IGNITION KEY

Case IH

2шт.

51

82017871

RELAY,12V, 20A

Isobus

1шт.

52

84157157

RELAY,12V, 20A, Micro

Micro, 12V-20A, on Main Fuse Box

1шт.

53

84157161

RELAY,12V, 20A

1шт.

54

84271717

RELAY,12V, 50A

Isobus

1шт.

55

84543528

RELAY,12V, 20A, Micro

1шт.

56

84577117

RELAY,12V, 2A

Isobus

1шт.

57

87341931

RELAY,Mini ISO, 12V, 70A

1шт.

58

87392809

RELAY,High Current, 12V, 190A

Battery Disconnect Switch, High Current

1шт.

59

87604032

RELAY,12V, 30A, Micro

3шт.

60

47478868

TEMPERATURE SENDER,35mm, Closed

EGT, 35mm, Closed

1шт.

61

47478880

TEMPERATURE SENDER,50mm, Closed

EGT, 50mm, Closed

1шт.

62

47493039

SENDER UNIT

Fuel Tank

1шт.

63

47520142

SENSOR,1000mm L

Nh3, 1000mm

1шт.

64

47582734

SENSOR,915mm Cable L

Nox, 915mm

1шт.

65

47582739

SENSOR,415mm Cable L

Nox, 415mm

1шт.

66

47664483

SENDER UNIT

DEF/ADBLUE™ Tank

1шт.

67

82028133

SENSOR,3/8"-18

Transmission Oil Temperature

1шт.

68

84243033

SENSOR

Speed, Transmission Gear

1шт.

69

84407735

PRESSURE SWITCH,0.40 Bar

Transmission Oil

1шт.

70

84465661

RADAR

Radar, UK

1шт.

71

84465662

SENSOR

True Ground Speed

1шт.

72

84479776

SENSOR

Fuel, W/ Water Separator, on Engine

1шт.

73

84539252

SENSOR

Air Filter, Temperature

1шт.

74

47767008

SENSOR

PTO Speed

1шт.

75

84579703

SENSOR

Temperature, Air Conditioner

1шт.

76

87605245

POTENTIOMETER,4000 Ohm, 13.5 VDC

Hydraulic Lift

1шт.

77

87605247

POTENTIOMETER,4000 Ohm, 13.5 VDC

Angle Position

1шт.

78

87661284

SENSOR

EDC Draft Pin on Lower Bar

1шт.

79

87675068

SENSOR

Front Axle, Angle Position

1шт.

80

47129450

SEAL KIT

Incl in P/N 5192186, Remote Valve Inlet Plate

1шт.

81

47590863

SEAL KIT

Rear Lift Cylinder

1шт.

82

47626694

SEAL KIT

4WD Steering Cylinder

1шт.

83

47630981

SEAL KIT

Hydraulic Top Link

1шт.

84

47748592

SERVICE KIT

DENOX Module, Protective Caps

1шт.

85

47748598

SERVICE KIT

DENOX Injector, Protective Caps

1шт.

86

47793355

SEAL KIT

Front Axle Suspension Cylinder

1шт.

87

47802538

SERVICE KIT

DENOX Module, Filter Cover

1шт.

88

84312718

SEAL KIT

Rear Remote Valve Element

1шт.

89

84530736

SEAL KIT

Incl in P/N 84530731, Front HPL Cylinder

1шт.

90

87382012

SEAL KIT

Incl in P/N 47370116, Female Quick Coupling

1шт.

91

87601759

SEAL KIT

Hydraulic Pump

1шт.

92

87728644

SEAL KIT

Suspension Control Valve

1шт.

93

84208903

STARTER MOTOR,12V, 4.2kW

1шт.

94

47132956

SENSOR

Hydraulic Creeper

1шт.

95

47132957

SENSOR

Hydraulic Creeper

1шт.

96

47452218

PRESSURE SWITCH

HVAC, A/C

1шт.

97

84416718

IGNITION SWITCH,50A

50A

1шт.

98

5165950

DISC

1шт.

99

5189182

CLUTCH PLATE,98.8mm ID x 139.11mm OD x 2.3mm Thk

1шт.

100

47127225

BRAKE DISC

Parking Brake

1шт.

101

47136624

CLUTCH PACK

Transmission Engagement

1шт.

102

47394940

BRAKE DISC

Transmission Brake, Extended Life

1шт.

103

47547826

CLUTCH PACK

Wet Differential Lock

1шт.

104

84557747

BRAKE DISC

N. 653

1шт.

105

47464490

WIPER MOTOR

Rear

1шт.

106

47611038

WIPER MOTOR

Front

1шт.

107

47611042

WIPER ARM,Single, 325mm L

Rear

1шт.

108

84488645

WIPER ARM,350mm L

Front, Single, 350mm

1шт.

109

84488646

WIPER BLADE,450mm L

Front, Single, 450mm

1шт.
