Запчасти Case IH FARMALL 110C (25.400.AF[01]) - VAR - 334216 - 2WD FRONT AXLE, SUPPORT (25) - FRONT AXLE SYSTEM

1

47626677

SUPPORT

2WD, Dark Grey

1шт.

2

84592829

PLATE

Dark Grey

1шт.

3

84408278

PLUG,Closing cavity

2шт.

4

16043420

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8, Full Thd

6шт.

5

84188434

WASHER,8.4mm ID x 16mm OD x 1.6mm Thk

8.4 x 16 x 1.6MM

6шт.

6

84398609

PIN,20mm OD x 25mm L

2шт.

7

15989134

BOLT,Hex, M20 x 1.5 x 100mm, Cl 10.9

2шт.

8

5174457

PAD

1шт.

9

11191879

BELLEVILLE WASHER,Belleville, 20mm ID x 38mm OD x 5.2mm Thk

20 x 38 x 5.2 ZNM

2шт.

10

87600545

BUTTON PLUG,M17 x 11.50mm

4шт.

11

81862738

PLUG,M38 x 28 x 5mm

2шт.
