(90.105.CQ) - STD + VAR - 390500 - BULKHEAD, INSULATING PANEL

Запчасти Case IH FARMALL 105U (90.105.CQ) - STD + VAR - 390500 - BULKHEAD, INSULATING PANEL (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH FARMALL 105U - (90.105.CQ) - STD + VAR - 390500 - BULKHEAD, INSULATING PANEL (90) - PLATFORM, CAB, BODYWORK AND DECALS
home
3
7
2
5
8
1
2
4
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84520373

SEAL

Frame

1шт.

2

12601274

WAVE WASHER,6.40mm ID x 12mm OD x 0.50mm, 2.60mm H, STL, DAC

7шт.

3

10720114

NUT,Hex, M6 x 1

6шт.

4

10902121

SCREW,Hex, M6 x 14mm, Cl 8.8

1шт.

5

84513291

INSULATOR

Frame

1шт.

6

84417854

INSULATOR

Lower

1шт.

7

84469346

SEAL

Upper

1шт.

8

84417625

INSULATOR

Upper

1шт.
