(88.100.AC[02]) - VAR - 332958 - LICENSE PLATE LAMP & SUPPORT, FENDER-MOUNTED, LEFT SIDE, ISO

Запчасти Case IH FARMALL 105U (88.100.AC[02]) - VAR - 332958 - LICENSE PLATE LAMP & SUPPORT, FENDER-MOUNTED, LEFT SIDE, ISO (88) - ACCESSORIES

Схема запчастей Case IH FARMALL 105U - (88.100.AC[02]) - VAR - 332958 - LICENSE PLATE LAMP & SUPPORT, FENDER-MOUNTED, LEFT SIDE, ISO (88) - ACCESSORIES
home
4
3
2
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

86980360

BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd

2шт.

2

12601274

WAVE WASHER,6.40mm ID x 12mm OD x 0.50mm, 2.60mm H, STL, DAC

2шт.

3

84529865

BRACKET

License Plate

1шт.

4

10720114

NUT,Hex, M6 x 1

2шт.
