Запчасти Case IH FARMALL 105U (35.204.BS[01]) - VAR - 744712 - REMOTE VALVES (35) - HYDRAULIC SYSTEMS

1

87733579

COUPLING

1шт.

2

84529495

BRACKET, SUPPORTING

1шт.

3

84529497

BRACKET, SUPPORTING

1шт.

4

84528805

BRACKET

1шт.

5

47403650

HYD TUBE

from MMV To Front Loader

1шт.

6

47403641

HYD TUBE

from MMV To Front Loader

1шт.

7

47403632

HYDRAULIC HOSE

from MMV To Front Loader

1шт.

8

47403630

HYDRAULIC HOSE

from MMV To Front Loader

1шт.

9

86579680

HYD CONNECTOR,1"-14 ORFS x M22 x 1.5mm ORB

ASSY, Incl 19 - 21

2шт.

10

87480324

HYD CONNECTOR

ASSY, Incl 20 - 22

2шт.

11

84309587

BRACKET

4шт.

12

16286424

BOLT,Hvy Hex, M6 x 35mm, Cl 8.8

4шт.

13

9804256

BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8

2шт.

14

84188434

WASHER,8.4mm ID x 16mm OD x 1.6mm Thk

4шт.

15

86625001

BOLT,Hex, M8 x 22mm, Cl 8.8, Full Thd

4шт.

16

86512447

CARRIAGE BOLT,Short Square Neck, M10 x 60mm, Class 8.8

2шт.

17

86511323

WASHER,10.5mm ID x 20mm OD x 2mm Thk

2шт.

18

100016

NUT,M10 x 1.5, Cl 8

2шт.

19

NSS

NOT SOLD SEPARAT

Connector, Incl in 9

1шт.

20

86598102

O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro

2шт.

21

9992069

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

2шт.

22

NSS

NOT SOLD SEPARAT

Connector, Incl in 10

1шт.

23

718844020

DIA KIT, TRACTOR

European Front Loader Bracket (MMV Not Included), with Mechanical and 80L Pump, Incl 1 - 22

1шт.

To See Full DIA KIT Composition Look for all the Figures Where the DIA KIT P/N Is Shown

1шт.
