Запчасти Case IH FARMALL 105U (35.162.AB[01]) - VAR - 331789, 744710 - FRONT LOADER, SUPPORT, CYLINDER (35) - HYDRAULIC SYSTEMS

1

47457860

PIN,31.5mm OD x 128mm L

1шт.

2

87588865

FITTING,M6 x 1 x 12mm L

2шт.

3

84470754

PIN,35mm OD x 113mm L

2шт.

4

87302865

SET SCREW,M8 x 16mm, Cl 8.8

2шт.

5

84313803

CARRIER

1шт.

6

14844834

SCREW,M18 x 1.5 x 80mm, Cl 10.9

4шт.

7

47362429

STUD,M16 x 85mm L

2шт.

8

5120218

GRILLE

1шт.

9

10520201

WASHER,16.4mm ID x 28mm OD x 3mm Thk

2шт.

10

10520301

WASHER,18.4mm ID x 32mm OD x 4mm Thk

4шт.

11

392530

NUT,M16, Cl 10

2шт.

12

47457844

LOCK PIN,12mm OD x 135mm L

ASSY, Incl 13, 14

1шт.

13

NSS

NOT SOLD SEPARAT

Pin, Incl in 12

1шт.

14

84561112

COTTER PIN,3.63mm x 54.25mm L

1шт.

15

47457843

PIN

ASSY, Incl 16, 17

1шт.

16

NSS

NOT SOLD SEPARAT

Pin, Incl in 15

1шт.

17

47458998

LINCH PIN,9.5mm OD x 62mm L

1шт.

18

5172480

BALL,25.4mm ID x 50mm OD

1шт.

19

47609242

ADJUSTMENT ROD

1шт.

20

84546176

TURNBUCKLE

1шт.

21

47437762

SPRING

1шт.

22

84546175

HOOK

1шт.

23

84534272

UPPER LINK

ASSY, Incl 19 - 22

1шт.

24

718747080

DIA KIT, TRACTOR

FHPL Chassis Mounted S/A with FPTO (Multifunctional Axle Support), Incl 1 - 23

1шт.

24

718746080

DIA KIT, TRACTOR

FHPL Chassis Mounted S/A less FPTO (Multifunctional Axle Support), Incl 1 - 23

1шт.
