Запчасти Case IH FARMALL 105C (90.102.AU[02]) - HOOD, LATCH (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

84278506

SUPPORT

, Years: -10-FEB-14

1шт.

1

47506412

SUPPORT

, Start Year: 11-FEB-14

1шт.

2

16043224

BOLT,Hex, M8 x 16mm, Cl 8.8

3шт.

3

86511839

BOLT,Hvy Hex, M6 x 30mm, Cl 8.8

4шт.

4

10004911

PIN,6mm OD x 17mm L

1шт.

5

10795101

COTTER PIN,M1.6 x 18

1шт.

6

84349450

LOCK

1шт.

7

10001071

YOKE,M6

1шт.

8

86500688

NUT,Hex, M6 x 1.0, Cl 10.9

1шт.

9

84329993

THREADED TIE-ROD

1шт.

10

84287785

BALL,5mm ID x 16mm OD

1шт.

11

10720114

NUT,Hex, M6 x 1

2шт.

12

84384258

U-BRACKET

1шт.

13

16043221

BOLT,Hex, M8 x 16mm, Cl 8.8, Full Thd

1шт.

14

11197774

BELLEVILLE WASHER,M6 Bolt Size x 12mm OD x 1.2mm Thk

6.4 x 12 x 1.2 x 1.63

4шт.

15

83962575

WASHER,6.6mm ID x 12.5mm OD x 1.6mm Thk

2шт.
