(1.40.0/12) - STANDARD FRONT AXLE WITH ELECTROHYDR. DIFF. LOCK LESS FRONT BRAKES (40 KM/H) - HYDRAULIC CYLINDER

Запчасти Case IH FARMALL 105V (1.40.0/12) - STANDARD FRONT AXLE WITH ELECTROHYDR. DIFF. LOCK LESS FRONT BRAKES (40 KM/H) - HYDRAULIC CYLINDER (04) - FRONT AXLE & STEERING

Схема запчастей Case IH FARMALL 105V - (1.40.0/12) - STANDARD FRONT AXLE WITH ELECTROHYDR. DIFF. LOCK LESS FRONT BRAKES (40 KM/H) - HYDRAULIC CYLINDER (04) - FRONT AXLE & STEERING
6
2
home
3
6
6
6
6
1
4
6
3
5
6
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84592007

RING

2шт.

2

5194202

STEERING CYLINDER

ASSY, Incl 3-6

1шт.

3

5194204

FLANGE

2шт.

4

5194203

ROD

1шт.

5

14274431

BOLT,Hex, M12 x 1.25 x 25mm, Cl 10.9

6шт.

6

5194205

SEAL KIT

Seals

1шт.

Выбрано товаров: 0
