1
4895164
SCREW,Hex, Flg Hd, M6 x 16
3шт.
2
2857015
HYD CONNECTOR,Hex, M12 x 1.5 x 6.7mm ID x 32mm L
ASSY, Incl 3, 4
1шт.
3
4895610
O-RING,2.2mm Thk x 9.3mm ID
1шт.
4
4899108
O-RING,0.364mm ID x 0.07mm Width
2шт.
5
4899467
GASKET
1шт.
6
4899519
CLAMP,M16, M6 Bolt
1шт.
7
4899106
HYD CONNECTOR,11/16" - 16 ORFS x M10 x 1.25 ORB
ASSY, Incl 4, 9
1шт.
8
2853842
FLEXIBLE HOSE,6.35mm ID x 347mm L
1шт.
9
4899106
HYD CONNECTOR,11/16" - 16 ORFS x M10 x 1.25 ORB
1шт.
10
2830895
TUBE
ASSY, Incl 11
1шт.
11
4899058
O-RING,0.674" ID x 0.88" OD x 0.103"
2шт.
12
4899057
FLANGE NUT,M6
1шт.
13
4893517
SCREW
1шт.
14
2830887
BRACKET
1шт.
15
4895089
PLUG,0.886" L
1шт.
