Запчасти Case IH FARMALL 95N (1.92.92[07]) - REAR WINDOW - HANDLE AND RELEVANT PARTS (10) - OPERATORS PLATFORM/CAB

Схема запчастей Case IH FARMALL 95N - (1.92.92[07]) - REAR WINDOW - HANDLE AND RELEVANT PARTS (10) - OPERATORS PLATFORM/CAB
13
8
1
14
2
3
8
10
15
11
5
6
1.92.92 06
home
12
9
10
4
7

Артикул

Название

Примечание

Количество

1

5186866

PLATE

1шт.

2

87473444

KNOB

1шт.

3

44911521

COVER PLATE

2шт.

4

12637878

SEALING WASHER,5.15mm ID x 11mm OD x 1mm Thk

2шт.

5

44911869

KNOB

1шт.

6

5147439

SUPPORT

2шт.

7

5182303

WASHER,8.4mm ID x 15mm OD x 0.8mm Thk

2шт.

8

5113395

SEAL, GLASS,Window, 30mm L

2шт.

9

5120540

KNOB

4шт.

10

5124800

SEALING RING,20mm ID x 36mm OD x 5mm Thk

SEALRING

6шт.

11

13311217

SCREW,Pozidriv Oval Hd, Csk, M5 x 20mm, Cl 5.8, Full Thd

2шт.

12

5131923

CAP,M8 x 11,5mm L

M8

2шт.

13

5108658

GASKET,25mm x 32mm

2шт.

14

83952214

BALL STUD,M8 x 29.5mm OAL

BALL PIN

2шт.

15

44911878

GAS STRUT,405mm Extended, 245mm Compressed

2шт.

16

87656446

HANDLE

Not Shown

1шт.

Выбрано товаров: 16
