(0.34.9) - BELT PULLEY DRIVE & COVER

Запчасти Case IH FARMALL 75N (0.34.9) - BELT PULLEY DRIVE & COVER (01) - ENGINE

Схема запчастей Case IH FARMALL 75N - (0.34.9) - BELT PULLEY DRIVE & COVER (01) - ENGINE
1
1
4
1
5
6
1
1
1
3
1
0.06.0
1
home
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

504255372

SUPPORT

ASSY, Incl 2-5

1шт.

2

4892732

BALL BEARING,34mm ID x 64mm OD x 37mm W

1шт.

3

4890732

RETAINER,11.50mm ID x 52mm OD x 7mm

1шт.

4

2852171

SNAP RING

1шт.

5

2854424

SCREW,Hex, Flg Hd, M10 x 1.5 x 70mm

M10 x 70

1шт.

6

2852247

BOLT,Hex, M8 x 1.25 x 30mm

M8 x 30

5шт.

Выбрано товаров: 6
