(1.82.4/01A) - ELECTRONIC LIFT - VALVE AND RELEVANT COMPONENTS.

Запчасти Case IH FARMALL 105N (1.82.4/01A) - ELECTRONIC LIFT - VALVE AND RELEVANT COMPONENTS. (07) - HYDRAULIC SYSTEM

Схема запчастей Case IH FARMALL 105N - (1.82.4/01A) - ELECTRONIC LIFT - VALVE AND RELEVANT COMPONENTS. (07) - HYDRAULIC SYSTEM
5
5
2
4
1
4
5
2
4
5
home
3
4
5
4
4
5
3
3
4
5
4
3
3
5
5
4
3
2
5
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

82011395

HYDRAULIC VALVE

ASSY, Incl 2-5

1шт.

2

82012223

SOLENOID,12V

Lower, Serial Range: -`0

1шт.

With Black Connector

1шт.

2

82012258

SOLENOID,12V

Raise, Serial Range: -`0

1шт.

With Red Connector

1шт.

3

83996684

HYDRAULIC VALVE

Poppet

1шт.

4

F0NNU920AA

KIT

Pilot

1шт.

5

83996689

SEAL KIT

1шт.
