1
47515027
AXLE HOUSING
Front, LH
1шт.
2
47515055
GAUGE
Axle Oil Level
1шт.
3
10839810
DOWEL,12mm OD x 18mm L
4шт.
4
455025
O-RING,0.139" Thk x 4.234" ID, -244, Cl 5, 75 Duro
2шт.
5
47515060
STUD
Spindle To Axle Housing
4шт.
6
11394321
BOLT,Hex, M14 x 1.5 x 45mm, Cl 8.8, Full Thd
8шт.
7
86639148
NUT,M14 x 1.5, Cl 8
4шт.
8
892-11014
LOCK WASHER,14.5mm ID x 24.1mm OD x 4.5mm Thk
12шт.
9
47515065
SEAL
Steering Knuckle, Incl 10 - 11
2шт.
10
47550070
SEALING RING
2шт.
11
274658
O-RING,0.21" Thk x 2.475" ID, -333, Cl 5, 75 Duro
2шт.
12
556884
BALL BEARING,65mm ID x 100mm OD x 18mm W
2шт.
13
47515068
SUPPORT
Bevel Gear
2шт.
14
47515073
SEAL
Steering Knuckle Cap
2шт.
15
86637970
BOLT,Hex, M12 x 1.25 x 35mm, Cl 8.8, Full Thd
8шт.
16
10571979
LOCK WASHER,M12
8шт.
17
47515077
SHIM
0.5mm Thk
1шт.
18
47515078
SHIM
0.8mm Thk
1шт.
19
47515081
SHIM
1.2mm Thk
1шт.
20
80710
LUBE NIPPLE,1/8” – 27 Dryseal PTF
2шт.
21
47542255
AXLE HOUSING
Front, RH
1шт.
22
47544430
SHIM KIT
Bevel Gear Shims, Incl 17 - 19
2шт.
