Артикул
Название
Примечание
Количество
1
710440046
DIA KIT, TRACTOR
Includes: Ref. 1A-48
1шт.
1a
86404401
BRACKET
Valve Mount
1шт.
2
87571203
HYDRAULIC VALVE
Hydraulic Valve Refer to Fig. 07.06.01
1шт.
3
87495969
HANDLE
Loader Valve
1шт.
4
50456
NUT,7/16"-20, G5
M5
1шт.
5
86071
HYD CONNECTOR,7/8" - 14 JIC x 3/4" - 16 ORB
Includes: 128825 O-Ring
1шт.
6
86509028
HYD CONNECTOR,3/4" - 16 JIC x 9/16" - 18 ORB
Includes: 9617873 O-Ring
2шт.
8
88574
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5, Full Thd
3шт.
9
86404405
TUBE,12.70 mm OD
Port A1
1шт.
10
86404407
TUBE,12.70 mm OD
Port A2
1шт.
11
86404409
TUBE,12.70 mm OD
Port B1
1шт.
12
86404411
TUBE,12.70 mm OD
Port B2
1шт.
13
87300892
HYD TUBE,12.70 mm OD
Tank
1шт.
14
86404415
TUBE,15.88 mm OD
Pressure
1шт.
15
87300891
HYD TUBE,15.88 mm OD
Power Beyond
1шт.
16
86402201
BRACKET
Tube Mount
1шт.
17
9846343
COUPLING,3/8" NPTF
Hydraulic, Female, O-Ring used is 122056 & Back-Up Ring used is 647327
4шт.
18
86597755
PLUG,29mm OD x 246mm L
Dust, Blue
1шт.
19
86597754
PLUG,29mm OD x 246mm L
Dust, Red
1шт.
20
86597758
PLUG,29mm OD x 246mm L
Dust, Yellow
1шт.
21
86597757
PLUG,29mm OD x 246mm L
Dust, Green
1шт.
22
86636626
ADAPTER,3/8"-18 Male NPTF x 3/8"-18 Female NPTF
1шт.
23
242679
HYD CONNECTOR,7/8" - 14 JIC x 3/8" - 18 NPT
2шт.
24
163334
HYD CONNECTOR,3/4" - 16 JIC x 3/8" - 18 NPTF
1шт.
25
182977
90 ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree Fem Sw
2шт.
26
248974
90 ELBOW,3/4" - 16 JIC x 3/4" - 16 Fem Sw
1шт.
27
86404403
PROTECTIVE COVER
Loader Control
1шт.
28
86511841
BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8
, Serial Range: -29
6шт.
29
86530982
BOOT
Loader Joystick
1шт.
30
86401095
DECAL
Loader Valve
1шт.
31
86401119
DECAL
Valve Lock
1шт.
32
86524859
CLAMP
Tube
2шт.
33
322357
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
2шт.
36
434097
SUPPORT
1шт.
38
86508570
BOLT,Hex, M6 x 80mm OAL, Cl 8.8
1шт.
39
353308
NUT,M6 x 1.0, Cl 8
1шт.
43
9601710
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, Pipe
1шт.
44
87039394
REDUCER,37 Degree, 3/4"-16, Fem x 7/8"-14 Male
Adapter
1шт.
46
81547
LOCK WASHER,7/16"
1шт.
47
87543390
HANDLE GRIP
Knob, Joystick
1шт.
48
87891
BHD LOCK NUT,Jam, 7/16"-20, G2
1шт.
Выбрано товаров: 48
