Запчасти Case IH FARMALL 50B (90.118.01) - STEPS & FLOOR MATS - 16X16 (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

MT40011634

BRACKET

Front Step

2шт.

2

MT40029395

BOLT,Hex, M14 x 2 x 35mm

Hex, M14 x 2P x 35L

4шт.

3

MT40029553

WASHER,14.20mm ID x 24.50mm OD x 3.50mm Thk

Spring, OD24.5 x ID 14.2 x 3.5T

4шт.

4

MT40163733

BRACKET

Mount Rear, LH

1шт.

5

MT40163732

BRACKET

Mount Rear, RH

1шт.

6

MT40008371

CAP

Bolt

2шт.

7

MT40012088

WASHER,71mm ID x 16.5mm OD x 4.5mm Thk

Rebound, OD16.5 x ID71 x 4.5T

4шт.

8

MT40007473

MOUNT,42mm OD x 3mmThk

D42 x 3T

4шт.

9

MT40029032

NUT,M16 x 1.5

Hex, M16 x P1.5

4шт.

10

MT40029479

BOLT,Hex, M16 x 1.5 x 60mm

Hex, M16 x 1.5P x 60L

4шт.

11

MT40028939

BOLT,Hex, M12 x 1.75 x 35mm

Hex, W/Washer, M12 x 1.75P x 35L

4шт.

12

MT40029075

FLANGE NUT,Hex, M8 x 1.25

Flange, M18 x P1.25

10шт.

13

MT40050189

FLOOR MAT

1шт.

14

MT40192519

STEP

Dark Gray

1шт.

15

MT40192525

STEP

Dark Gray

1шт.

16

MT40159913

STEP

Center

1шт.

17

MT40011227

FRAME

Mud Guard, LH

1шт.

18

MT40011228

FRAME

Mud Guard, RH

1шт.

19

MT40008373

PLATE

Mud Guard

2шт.

20

MT40008374

SPACER

Glasss

4шт.

21

MT40028674

SCREW,M8 x 1.25 x 25mm L

M8 x 1.25P x 25L

4шт.

22

MT40007407

STOP DEVICE,22mm OD x 2mm ID x 8mm Thk

Front Mount, OD22 x ID2x8 T

2шт.

23

MT40011713

STEP

Sub

2шт.

24

MT40012492

BRACKET

Center Mount

2шт.

25

MT40007351

RUBBER SLEEVE

Center Mount, D10 x 20L

2шт.

26

MT40028921

BOLT,Hex, M8 x 1.25 x 20mm

Hex, W/Washer, M8 x 1.25P x 20L

4шт.

27

MT40029006

BOLT,Hex, M8 x 1.25 x 20mm

Hex, W/Washer, M8 x 1.25P x 20L

12шт.

28

MT40029555

WASHER,16.20mm ID x 28mm OD x 4mm Thk

Spring, OD28 x ID16.2 x 4T

4шт.

29

MT40007357

GROMMET,21mm OD x 23mm Thk

Wiper Front, D21 x 2.3T

1шт.

30

MT40007334

SEALING STRIP

38L

1шт.

31

MT20119015

DIA KIT, TRACTOR

Kit, Step Includes: Ref. 23-27 Refer to Fig. 88.100.07

1шт.

USED ON & PIN # 2103012263 BOOMER 40 & 2105011935 BOOMER 50

1шт.
