1
GRT3484433
VALVE BLOCK
Torque Sensor Inlet Pipe
1шт.
2
87481398
SCREW,M8 x 1.25 x 1.25mm
M8x1.25x35
10шт.
3
84145860
BOLT,Hex, M10 x 1.25 x 30mm, Cl 8.8
M10X1.36X30 CL 8.8
4шт.
4
87481341
DIPSTICK
Oil
1шт.
5
84146969
COVER
HPL Lift
1шт.
6
84145865
BOLT,Hex, M12 x 1.25 x 130mm, Cl 8.8
M12X1.25X130 CL 8.8
3шт.
7
GRT3VT01393
PIPE
Piv Hydraulic Block Inlet Pipe
1шт.
8
GRT72314
O-RING,0.103" Thk x 0.75" ID, -116, Cl 7, 75 Duro
Seal, 2.62x21.89
1шт.
9
NS
NOT SERVICED
Dowel
1шт.
10
NS
NOT SERVICED
Anti-Rotation Disc Stopping Pin
1шт.
11
GRT70052
BREATHER
Breather
1шт.
12
84145868
BOLT,Hex, M12 x 1.25 x 45mm, Cl 8.8
M12X1.25X45 CL 8.8
1шт.
13
84145866
BOLT,Hex, M12 x 1.25 x 35mm, Cl 8.8
M12X1.25X35 CL 8.8
1шт.
14
87481406
RING
Anti-Extrusion
1шт.
15
87481342
O-RING,9.25MM ID x 1.78MM Width
Seal, 1.78x9.25
1шт.
16
87481351
O-RING
1.78x9.75
1шт.
17
84163663
GASKET
Gasket, Variator Control Unit
1шт.
18
GRT3VT01843
PRESSURE SWITCH
Switch Pressure
1шт.
19
84163670
VALVE
Valve, Stand Still
1шт.
20
84163673
COIL
Coil
1шт.
