1
47886995
PLATFORM
Operators
1шт.
1
47886989
PLATFORM
Operators
1шт.
2
120041
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
2шт.
3
86549816
PUSH-ON NUT
9mm ID x 19.87mm OD
2шт.
4
140045
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
2шт.
5
9804278
FLANGE NUT,M10 x 1.5, Cl 8
6шт.
6
86625221
HEX SOC SCREW,M8 x 30mm, Cl 8.8
2шт.
7
322358
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
2шт.
8
9804277
FLANGE NUT,Hex, M8 x 1.25, Cl 8
2шт.
9
86524667
WASHER,M10.3 x 38.1 x .15 Thk
10шт.
10
9804265
FLANGE BOLT,Hex, M10 x 60mm, Cl 8.8
4шт.
11
86558389
DAMPER
33.3mm OD x 30.7mm Thk
4шт.
12
134857
GROMMET
11.1125mm ID x 23.8125mm OD X 9.525mm Thk
1шт.
13
86558468
ROD
HPL Rate Control
1шт.
14
86558451
KNOB
HPL Rate Control
1шт.
15
180042
BOLT,Hex, 1/4" - 20 x 1 3/4", Gr 5
1шт.
16
9628503
NUT,3/8"-16, G5
1шт.
