Запчасти Case IH DX29 (05F03) - HYD PIPING W/HST ON & ASN HBA0001480 (07) - HYDRAULIC SYSTEMS

Схема запчастей Case IH DX29 - (05F03) - HYD PIPING W/HST ON & ASN HBA0001480 (07) - HYDRAULIC SYSTEMS

Артикул

Название

Примечание

Количество

1

SBA340560440

FILTER HEAD

HEAD, FILTER, Flange, When ordering Flange also order Ref. 1A & 1B

1шт.

1a

SBA048100016

BALL

1шт.

1b

SBA398213390

SPRING

1шт.

2

SBA340501030

FILTER

Oil, HST, W/Internal Bypass

1шт.

3

SBA340708990

HYD TUBE

TUBE, HYD

1шт.

4

SBA340708970

PIPE

1шт.

5

SBA340706631

PIPE

1шт.

6

SBA340708960

HYD TUBE

TUBE, HYD

1шт.

7

SBA398750260

HOSE CLAMP

1шт.

8

SBA398480240

BANJO BOLT,3/8"

BOLT, BANJO, , PF 3/8"

3шт.

9

86511315

WASHER,8.4mm ID x 16mm OD x 1.8mm Thk

1шт.

10

SBA398480250

BANJO BOLT,1/2"

BOLT, BANJO, 1/2"

1шт.

11

SBA052100160

O-RING

P16

2шт.

12

SBA398115670

HOSE

Rubber

1шт.

13

87300044

HYDRAULIC OIL FILTER

Filter, Oil, Pump/Transmission

1шт.

14

SBA011510816

BOLT

M8 x 16

8шт.

15

SBA322800181

TRANSMISSION, HYDROS

HST Assy

1шт.

16

SBA340750260

BODY

Oil Filter

1шт.

17

86530711

HYDRAULIC HOSE,15.88 mm ID x 70.00 mm, SAE 30R2 Type 1

- Cooler, HST 15.88 mm ID x 70.00 mm, SAE 30R2 Type 1

1шт.

18

86402606

BRACKET

HST Filter

1шт.

19

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

20

86511841

BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8

Hex Flg Hd, CL 8.8, M8 x 1.25 x 16

2шт.

21

86526913

BOLT,Hex, M14 x 45.5mm, Cl 10.9

2шт.

22

86524957

TUBE,469, 245.8 mm L

HST Cooler

1шт.

23

86522970

TUBE,15.90 mm ID x 17.00 mm OD

HST Cooler

1шт.

24

SBA052300250

O-RING

2шт.

25

SBA052100200

O-RING,2.4mm Thk x 19.8mm ID, 70 Duro

9шт.

26

SBA052100140

O-RING

1шт.

27

SBA011310640

CAPTIVE WASHER SCREW,Hex, M6 x 40, Cl 8.8

SCREW, CAPTIVE WASHER, Hex, M6 x 40, Cl 8.8

2шт.

28

SBA340673860

HYD CONNECTOR

CONNECTOR, HYD.

1шт.

Выбрано товаров: 30
