Артикул
Название
Примечание
Количество
1
86402749
LOWER LINK
RH, Includes: Ref. 2 - 8
1шт.
2
86402625
LIFT LINK END ASSY
Extension, RH
1шт.
3
14610270
LOCK PIN,M10 x 45, Slotted
1шт.
5
86402627
COVER
1шт.
6
86402636
LOWER LINK
1шт.
7
86400412
CLEVIS PIN,15.88mm OD x 63mm L
(5/8"), Uses 87398 Cotter Pin
1шт.
8
86532826
SPRING,Extension, 60.7mm L
1шт.
9
86400412
CLEVIS PIN,15.88mm OD x 63mm L
(5/8"), Uses 87398 Cotter Pin
2шт.
10
86402750
LOWER LINK
LH, Includes: Ref. 11 - 17
1шт.
11
86402626
LIFT LINK END ASSY
Extension, LH
1шт.
12
14610270
LOCK PIN,M10 x 45, Slotted
1шт.
14
86402627
COVER
1шт.
15
86402636
LOWER LINK
1шт.
16
86400412
CLEVIS PIN,15.88mm OD x 63mm L
(5/8"), Uses 87398 Cotter Pin
1шт.
17
86532826
SPRING,Extension, 60.7mm L
1шт.
18
86402629
LIFT LINK
LH
1шт.
19
86402637
LIFT LINK
Top, Includes: Ref. 20 - 23
1шт.
20
86402717
HOUSING
1шт.
21
86558206
BALL JOINT
Rod End, RH
1шт.
22
86558207
BALL JOINT,M24 x 3, LH Threads
Rod End, LH
1шт.
23
86400234
JAM NUT
1шт.
24
SBA370911000
PIN
1шт.
24
SBA370911000
PIN
1шт.
25
SBA370910060
PIN
2шт.
26
SBA398213410
SPRING
2шт.
27
86402632
LEVELLING DEVICE
Includes: Ref. 28 Thru 30
1шт.
28
86402633
GEAR
Rod End
1шт.
29
86400283
LIFT LINK
Clevis
1шт.
30
86400284
LOCK
Crank
1шт.
31
86400289
STABILIZER
Male
2шт.
32
86400288
STABILIZER
Female
2шт.
33
86400280
PIN
Stabilizer w/Chain
2шт.
35
100038
NUT,M12 x 1.75, Cl 8
4шт.
35
100038
NUT,M12 x 1.75, Cl 8
4шт.
36a
86523778
COTTER PIN,3/8" x 2"
2шт.
37
80756
COTTER PIN,1/8" x 3/4"
2шт.
38
9804270
BOLT,Hex, M12 x 60mm, Cl 8.8
4шт.
39
SBA370900700
PIN
2шт.
40
SBA011511230
BOLT,M12 x 30
4шт.
41
86402517
KIT
Rear Counterweight Bracket, Mounts on 3-Point Hitch & Will Accept Up To (7) Front End Weights.n
1шт.
Includes: PBF9590 Pin Assy.
1шт.
Выбрано товаров: 47
