1
SBA010810875
BOLT
2шт.
2
SBA010819002
BOLT
2шт.
3
SBA322800201
TRANSMISSION, HYDROS
HST Refer to Fig. 03.05.01 for Breakdown
1шт.
SBA322800202R
REMAN-HYDROSTAT PUMP
DX22E, DX25E Both(1/05), DX18E PIN # HDG110000 & ABOVE (4/05), Reman for new P/N SBA322800201
1шт.
SBA322800202C
CORE-HYDROSTAT PUMP
Return Number
1шт.
3
SBA322800202
TRANSMISSION, HYDROS
HST Refer to Fig. 03.05.01 for Breakdown
1шт.
USED ON & ABOVE PIN HDG110101 DX18E, HDG710073 DX22E & HDG210400 DX25E
1шт.
SBA322800202R
REMAN-HYDROSTAT PUMP
DX22E, DX25E Both(1/05), DX18E PIN # HDG110000 & ABOVE (4/05)
1шт.
SBA322800202C
CORE-HYDROSTAT PUMP
Return Number
1шт.
4
SBA322280250
WASHER
1шт.
5
SBA011510820
CAPTIVE WASHER SCREW,Hex, M8 x 20, G5
2шт.
6
SBA052109076
O-RING,2.4mm Thk x 10.8mm ID
P11
1шт.
7
SBA010810825
BOLT
9шт.
8
SBA030500616
DOWEL,M6 x 16
1шт.
9
SBA322213890
COVER
1шт.
10
SBA064409006
PLUG,1/8" NPT
2шт.
11
SBA052300600
O-RING,G60
1шт.
12
SBA052300750
O-RING
1шт.
13
SBA052400500
O-RING
1шт.
14
SBA399235840
SEALING RING COLLAR
1шт.
15
SBA010810835
BOLT
2шт.
16
SBA030500825
PIN
Dowel, M8 x 25
8шт.
17
28042460
BALL BEARING,30mm ID x 55mm OD x 13mm W
2шт.
18
370003
SNAP RING,M30, External
1шт.
19
SBA322326560
GEAR
Fixing
1шт.
20
210041
BALL BEARING,25mm ID x 52mm OD x 15mm W
1шт.
21
370002
CIRCLIP,M25, External
1шт.
22
SBA399260650
THRUST WASHER
2шт.
23
SBA322382960
GEAR
Counter
1шт.
24
SBA042209024
NEEDLE
Bearing
2шт.
25
SBA399370620
NUT
Lock
1шт.
26
SBA322326570
GEAR
Fixing
1шт.
27
SBA042530207
BEARING ASSY
Taper, M35 x 72 x 18.25
2шт.
28
SBA199280690
SHIM,0.1mm Thk
1шт.
29
SBA199280700
SHIM,0.2mm Thk
1шт.
30
SBA199280710
SHIM,0.5mm Thk
1шт.
31
SBA064500020
PLUG
1/4"
1шт.
31
SBA064409008
PLUG
1шт.
USED ON & ABOVE PIN HDG110114 DX18E, HDG710101 DX22E, HDG210548 DX25E
1шт.
32
SBA322118500
CASING
1шт.
32
SBA322118502
CASING
1шт.
USED ON & ABOVE PIN HDG110106 DX18E, HDG710097 DX22E, HDG210545 DX25E
1шт.
33
SBA012111040
SCREW
Stud, M10 x 40
2шт.
34
SBA025100010
SEALING WASHER,9.2mm ID x 17mm OD x 1.8mm Thk
M10
1шт.
35
SBA399430190
BOLT
M10
1шт.
36
SBA025100016
WASHER,16.4mm ID x 27mm OD x 2mm Thk
Seal, #16
1шт.
37
SBA064600016
PLUG
M16
1шт.
38
SBA322051380
DRIVE
Pinion
1шт.
39
SBA355520880
PLATE
1шт.
40
SBA010109611
BOLT
1шт.
