Запчасти Case IH C-2 (J-08) - MOUNTING & DRIVE PARTS, 140 TRACTORS
№
Артикул
Название
Примечание
Количество
1
474043R91
BRACKET ASSY, rear mounting
1шт.
80280173
BOLT,Hex, 3/4" - 10 x 2 3/4", Gr 5
SCREW, 3/4-10 x 2-3/4 cd or zn-pltd hex-hd cap
4шт.
87340
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
WASHER, LOCK, 3/4"
4шт.
2
474044R1
PLATE, mounting bracket spacer
2шт.
2
474045R1
PLATE, mounting bracket spacer, used only when tractor is not equipped w/fast hitch
2шт.
3
474046R1
BRACKET
platform pivot
2шт.
180179
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 5
SCREW, 1/2-13 x 1-3/4 cd or zn-pltd hex-hd cap, pivot bracket mounting bracket
2шт.
495-11053
WASHER,1/2", SAE
17/32 x 1-1/16 x .095 cd or zn-pltd
2шт.
180175
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
SCREW, 1/2-13 x 1-1/4 cd or zn-pltd hex-hd cap, pivot bracket to platform angles
4шт.
120384
WASHER,1/2"
LOCK, 1/2"
6шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
6шт.
4
474047R1
SPACER
BUSHING, platform pivot
2шт.
5
474048R1
ARM, chain lift
1шт.
6
474049R91
CHAIN W/SHACKLE, platform lift
1шт.
7
474050R91
CLEVIS
SHACKLE W/SCREW PIN, anchor
1шт.
180122
BOLT,Hex, 3/8" - 16 x 1", Gr 5
3/8-16 x 1 cd or zn-pltd hex-hd cap, chain to platform lift angles
2шт.
120394
WASHER,3/8", SAE
WASHER, 13/32 x 13/16 x .065 cd or zn-pltd
4шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
2шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
8
474051R91
BRACKET ASSY, idler swivel
1шт.
180177
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5
SCREW, 1/2-13 x 1-1/2 cd or zn-pltd hex-hd cap
2шт.
495-11053
WASHER,1/2", SAE
17/32 x 1-1/16 x .095 cd or zn-pltd
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
9
474052R91
PULLEY
W/BEARING, flat idler
1шт.
426-1040
BOLT,Hex, 5/8" - 11 x 2-1/2", Gr 8
SCREW, 5/8-11 x 2-1/2 cd or zn-pltd hex-hd cap
1шт.
446239
WASHER, 5/8 x 1-3/8 x .109 cd or zn-pltd
5шт.
492-11062
BEARING WASHER,5/8"
WASHER, LOCK, 5/8"
1шт.
10
574094R91
PULLEY W/BEARING, v-idler
1шт.
11
474053R91
BOLT
ASSY, idler pulley
1шт.
446239
WASHER, 5/8 x 1-3/8 x .132 cd or zn-pltd
4шт.
492-11062
BEARING WASHER,5/8"
WASHER, LOCK, 5/8"
1шт.
12
474054R1
V-BELT,0.70" W x 164.85" L
V-section drive 0.70" W x 164.85" L
1шт.
13
474055R1
SHEAVE, drive
1шт.
14
474056R1
HUB
drive sheave splined
1шт.
180043
COTTER PIN
SCREWM 1/4-20 x 1-7/8 cd or zn-pltd hex-hd cap
3шт.
492-11025
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
3шт.
Q3482
WASHER
1-5/32 x 1-3/4 x 11 ga, between drive sheave hub & tractor belt pulley gear box
2шт.
474057R91
GUARD ASSY, rear belt
1шт.
180122
BOLT,Hex, 3/8" - 16 x 1", Gr 5
3/8-16 x 1 cd or zn-pltd hex-hd cap
1шт.
120394
WASHER,3/8", SAE
WASHER, 13/32 x 13/16 x .065 cd or zn-pltd
2шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
1шт.
120377
NUT,3/8" - 16, Gr 5
1шт.
Выбрано товаров: 46
