Запчасти Case IH C-2 (G-42) - MOUNTING & DRIVE PARTS, INTERNATIONAL CUB LO-BOY TRACTORS

1

474058R91

BRACKET ASSY, idler

1шт.

113-233

BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5

3/8-16 x 1-3/4 C-Z hex-hd cap

4шт.

2

474059R91

BRACKET ASSY, left pivot

1шт.

180177

BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5

SCREW, 1/2-13 x 1-1/2 C-Z hex-hd cap

1шт.

120396

WASHER

17/32 x 1-1/16 x .095

2шт.

120384

WASHER,1/2"

LOCK, 1/2"

1шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

1шт.

NLS

NO LONGER SERVICED

SCREW, 5/8-11 x 1-1/2 C-Z hex-hd cap

2шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

3

474060R91

BRACKET ASSY, right pivot

1шт.

180177

BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5

SCREW, 1/2-13 x 1-1/2 C-Z hex-hd cap

1шт.

NLS

NO LONGER SERVICED

17/32 x 1-1/16 x .095 C-Z

2шт.

120384

WASHER,1/2"

LOCK, 1/2"

1шт.

271547

STUD,Hex, 5/8" - 11 x 1 1/2", Gr 5

SCREW, 5/8-11 x 1-1/2 C-Z hex-hd cap

2шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

1шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

4

474061R2

SPACER

BUSHING, platform pivot

2шт.

5

474062R1

ARM, lift chain

1шт.

6

474063R1

STRAP, lift chain pivot

1шт.

271715

BOLT,Hex, 5/8" - 11 x 1", Gr 5

SCREW, 5/8-11 x 1 C-Z hex-hd cap

1шт.

NLS

NO LONGER SERVICED

SCREW, 5/8-11 x 1-1/2 C-Z hex-hd cap

1шт.

NLS

NO LONGER SERVICED

SCREW, 5/8-11 x 1-3/4 C-Z hex-hd cap

1шт.

396-21066

WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk

21/32 x 1-5/16 x .095 C-Z

3шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

3шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8-11 C-Z hex.

2шт.

7

474064R1

WASHER

BUSHING, lift chain arm pivot

3шт.

8

474065R1

ANGLE, lift chain mounting

1шт.

180175

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

SCREW, 1/2-13 x 1-1/4 C-Z hex-hd cap

1шт.

120384

WASHER,1/2"

LOCK, 1/2"

1шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

1шт.

9

474066R91

CHAIN W/SHACKLES, platform lift

1шт.

10

474050R91

CLEVIS

SHACKLE W/SCREW PIN, anchor

2шт.

11

662959R91

PULLEY ASSY.

PULLEY W/BEARING, v-idler

2шт.

12

474053R91

BOLT

ASSY, idler pulley

2шт.

446239

WASHER, 5/8 x 1-3/8 x .109 C-Z

9шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

124589

BALL STUD,Hex, 5/8" - 11 x 2", Gr 5

5/8-11 C-Z hex.

2шт.

13

477180R1

V-BELT,0.70" W x 138.85" L

V-section drive 0.70" W x 138.85" L

1шт.

14

474067R1

PULLEY

SHEAVE, drive

1шт.

15

474068R1

HUB

drive sheave splined

1шт.

326-420

BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 8

SCREW, 1/2-20 x 1-1/8 C-Z hex-hd cap

2шт.

474069R1

GUARD

rear belt

1шт.

16

474070R1

LUG, belt guard mounting

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

120377

NUT,3/8" - 16, Gr 5

2шт.
