Артикул
Название
Примечание
Количество
1
491881R2
PULLEY
driver
1шт.
21985R1
PIN, 3/16 x 2 C-Z cot.
1шт.
2
541556R2
BRACKET
ASSY, idler support
1шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
4шт.
120377
NUT,3/8" - 16, Gr 5
4шт.
3
543125R2
PULLEY
mule drive idler, replaces 491819R91 by also ordering bearing 543126R91 and two rings 273026R1
2шт.
113-233
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
3/8-16 x 1-3/4 znd hex-hd cap
1шт.
180130
BOLT,Hex, 3/8" - 16 x 2", Gr 5
SCREW, 3/8-16 x 2 znd hex-hd cap
1шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
2шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
4
492102R1
BELT
Mule drive
1шт.
5
492103R1
V-BELT
Spindle drive
1шт.
6
542520R91
PULLEY
flat idler
1шт.
7
486355R1
ARM
ASSY, idler
1шт.
120377
NUT,3/8" - 16, Gr 5
1шт.
271501
SOCKET
NUT, 7/16-14 C-Z hex.
1шт.
180122
BOLT,Hex, 3/8" - 16 x 1", Gr 5
3/8-16 x 1 znd hex-hd cap
1шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
1шт.
120383
LOCK WASHER,Helical Spring, 7/16"
WASHER, LOCK, 7/16"
1шт.
142619H
WASHER
13/32 x 3/4 x 11 ga C-Z
1шт.
469668R1
WASHER
13/32 x 3/4 x 16 ga C-Z
1шт.
188755R1
WASHER
15/32 x 1-1/2 x 11 ga C-Z
2шт.
8
385525R1
LOCK NUT,3/8"-16, GB
NUT, 3/8-16 CPD hex. lock
2шт.
9
486360R1
BOLT
BOLT, idler arm pivot
1шт.
10
491883R1
SPRING
torsion
1шт.
11
491884R11
SHIELD
ASSY, rear
1шт.
12
492970R2
SHIELD
lower
1шт.
120376
NUT,5/16"-18, G5
1шт.
88574
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5, Full Thd
5шт.
20484R1
BOLT,Hex, 5/16" - 18 x 6 1/2", Gr 5
SCREW, 5/16-18 x 6-1/2 znd hex-hd cap
1шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
6шт.
120393
BEARING WASHER,5/16", SAE
WASHER, 11/32 x 11/16 x .065 C-Z
6шт.
13
491997R1
SPACER,3/8" X-Strng Pipe x 5 3/4"
3/8 x 5.75 extra strong pipe
1шт.
14
491887R1
PULLEY
outer LH
1шт.
15
491888R1
PULLEY
outer RH
1шт.
16
543120R1
PULLEY
center
1шт.
17
540024R1
SPACER, idler arm assy
1шт.
18
541554R1
BOLT,Shoulder, Hex, 5/8" - 11 x 4.10"
shoulder
1шт.
492-11062
BEARING WASHER,5/8"
WASHER, LOCK, 5/8"
1шт.
19
541553R2
ARM
ASSY, idler
1шт.
20
541549R1
SPRING
idler torsion
1шт.
21
543126R91
BALL BEARING,19.33mm ID x 34.92mm OD x 23.14mm W
ASSY, pulley ball
2шт.
22
273026R1
SNAP RING,1.375", Int, #137
Ring, Snap, , brg 1.375", Int, #137
4шт.
Выбрано товаров: 45
