Запчасти Case IH W930 (05) - PLATFORM, PAGE 87 CATALOG 678 (09) - CHASSIS

A11703

Platform - L.H. (Agricultural tractor)

1шт.

A21853

Platform - L.H. (Industrial tractor)

1шт.

A20485

Brace - platform, lower

2шт.

A20486

Brace - fender, rear

2шт.

14-1032

BOLT,Hex, 5/8" - 18 x 2", Gr 5

(A20485 and A20486 to drawbar channel) Hex, 5/8"-18 x 2", G5

2шт.

25-1110

NUT,5/8"-18, G5

- 5/8" N.F. hex. (For 14-1032)

2шт.

92-10

LOCK WASHER,5/8"

WASHER, LOCK, (For 14-1032) 5/8"

2шт.

1

A21852

Angle - drawbar guide

1шт.

2

13-1240

BOLT,Hex, 3/4" - 10 x 2-1/2", Gr 5

2шт.

3

92-12

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

4шт.

4

13-1248

BOLT,Hex, 3/4" - 10 x 3", Gr 5

2шт.

5

A20829

Drawbar - with yoke

1шт.

6

A20711

Bracket - drawbar pivot, with plate

1шт.

7

14-1240

BOLT,Hex, 3/4" - 16 x 2-1/2", Gr 5

- 5/8" x 2-1/2" N.F. hex.

2шт.

8

25-1110

NUT,5/8"-18, G5

- 5/8" N.F. hex.

2шт.

9

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

10

6134AB

Bushing - front, drawbar channel

2шт.

11

6135AB

Bushing - rear, drawbar channel

2шт.

12

6087AB

Bolt - drawbar pivot

1шт.

13

7969AB

Pin - drawbar guide

1шт.

14

6396AB

Clip - drawbar pivot bolt holder (Hyd. hsg. at transmission case)

1шт.

A23027

Seat - operator's, complete (Replaces A22807 on Industrial tractor), case deluxe seat (Figure 31 supplement no. 1-cat. no. 678)

1шт.

D22821

Rest - seat back (Replaces A22842 on Industrial tractor), case deluxe seat (Figure 31 supplement no. 1-cat. no. 678)

1шт.

D22822

Cushion - seat (Replaces A22843 on Industrial tractor), case deluxe seat (Figure 31 supplement no. 1-cat. no. 678)

1шт.
