Запчасти Case IH B414 (156[B]) - MISCELLANEOUS EQUIPMENT, PACKAGE ASSORTED GASKETS - DIESEL ENGINE TRACTORS Miscellaneous Equipment

3041249R92

GASKET KIT

GASKET SET, CRANKCASE (DIESEL ENGINE), INCLUDES: REF. 1 - 19

1шт.

1

708285R1

GASKET

CRANKCASE FRONT COVER GASKET

1шт.

2

709903R1

GASKET

CRANKCASE FRONT PLATE GASKET

1шт.

3

703840R1

GASKET

CRANKCASE OIL PAN GASKET

1шт.

4

708907R1

GASKET

CRANKSHAFT REAR OIL SEAL RETAINER GASKET

1шт.

5

703883R6

GASKET

CYLINDER HEAD GASKET

1шт.

6

704165R2

MANIFOLD GASKET

EXHAUST MANIFOLD GASKET

2шт.

7

3043370R1

GASKET

FUEL FEED PUMP GASKET

1шт.

8

3061658R1

GASKET

FUEL FEED PUMP GASKET

1шт.

9

703851R1

GASKET

HYDRAULIC PUMP OPENING COVER GASKET

1шт.

10

708289R1

BOLT

INJECTION PUMP GASKET

1шт.

11

703849R1

GASKET

INJECTION PUMP GEAR COVER GASKET

1шт.

12

704162R1

MANIFOLD GASKET

INTAKE MANIFOLD GASKET

2шт.

13

706592R1

GASKET

OIL FILTER BASE GASKET

1шт.

14

3405H

GASKET

OIL PAN DRAIN PLUG GASKET

1шт.

15

710382R3

GASKET,29mm ID x 35mm OD x 1.22mm Thk

PRE-COMBUSTION CHAMBER GASKET-UPPER

4шт.

16

719383R1

GASKET

PRE-COMBUSTION CHAMBER GASKET-LOWER

4шт.

17

703815R1

GASKET

THERMOSTAT HOUSING GASKET

1шт.

18

703896R1

GASKET

VALVE COVER GASKET

1шт.

19

703816R1

GASKET

WATER PUMP GASKET

1шт.

706105R93

GASKET KIT

GASKET SET, VALVE GRINDING (DIESEL ENGINE), INCLUDES: REF. 20 - 26

1шт.

20

703883R6

GASKET

CYLINDER HEAD GASKET

1шт.

21

704165R2

MANIFOLD GASKET

EXHAUST MANIFOLD GASKET

2шт.

22

704162R1

MANIFOLD GASKET

INTAKE MANIFOLD GASKET

2шт.

23

710382R3

GASKET,29mm ID x 35mm OD x 1.22mm Thk

PRE-COMBUSTION CHAMBER GASKET-UPPER

4шт.

24

710383R1

GASKET

PRE-COMBUSTION CHAMBER GASKET-LOWER

4шт.

25

703815R1

GASKET

THERMOSTAT HOUSING GASKET

1шт.

26

703896R1

GASKET

VALVE COVER GASKET

1шт.

385584R91

PACKAGE, HYDRAULIC LIFT O-RING AND GASKET SERVICE, INCLUDES: REF. 27 - 47

1шт.

27

3061055R1

GASKET

AUXILIARY VALVE COVER PLATE

2шт.

28

751499R1

GASKET

HOUSING COVER PLATE

1шт.

29

3044392R1

GASKET

QUADRANT BRACKET

1шт.

30

3044367R1

GASKET

TOP COVER PLATE

1шт.

31

3044437R1

GASKET

VALVE BODY

1шт.

32

3044436R1

O-RING,0.21" Thk x 2.6" ID, -334, Cl 5, 75 Duro

CYLINDER

1шт.

33

704378R1

O-RING,0.139" Thk x 0.85" ID

DEPTH CONTROL

2шт.

34

707747R1

SCRAPER RING

O-RING, FLOW CONTROL VALVE BORE

1шт.

35

704753R1

GASKET,0.103" Thk x 0.674" ID, -115, Cl 6, 90 Duro

O-RING, PRESSURE OUTLET

2шт.

36

704348R1

O-RING,0.139" Thk x 1.687" ID, Cl 5

O-RING, SUCTION FILTER

1шт.

37

361883R1

O-RING

7/32 x 11/32 x 1/16

1шт.

38

706584R1

GASKET

O-RING, 1/4 x 3/8 x 1/16

2шт.

39

708444R1

GASKET,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro

O-RING, 5/16 x 7/16 x 1/16

1шт.

40

355966R1

O-RING,0.424" ID x 0.103" Width

7/16 x 5/8 x 3/32

3шт.

41

704219R2

WASHER

O-RING, 9/16 x 3/4 x 3/32

4шт.

42

3045116R1

O-RING,0.103" Thk x 0.469" ID, Cl 6

O-RING, 21/32 OD x 15/32 ID

1шт.

43

254691R1

O-RING,-211, 70 Duro, .796" ID x .139" Thk

13/16 x 1-1/16 x 1/8

2шт.

44

702816R1

WASHER

O-RING, 1-1/4 x 1 x 1/8

1шт.

45

3045118R1

SEAL

WASHER, DOWTY

1шт.

46

751560R1

COPPER WASHER

9/32 x 23/32 x 16 GA

1шт.

47

704337R1

SEALING WASHER

WASHER, 1/2 BSP SEALING

2шт.
