Запчасти Case IH 884 (13-054) - ROOF -SEKURA- (05) - SUPERSTRUCTURE

3123084R92

PANEL ASSY.

CPTE ROOF OUTER, CONSISTS ITEMS 1-5 AND 18-20 INCLUSIVE

1шт.

1

3123830R1

GRILLE

AIR INTAKE

2шт.

2

3123829R1

CAB FILTER

AIR INTAKE

2шт.

3

3123669R1

PROTECTION STRIP

EDGING

2шт.

4

PANEL, OUTER ROOF, NOT SERVICED SEPARATELY

1шт.

5

3123828R1

SEAL

SEAL, HATCH

1шт.

6

3123832R1

HANDLE

INSULATOR, HATCH DOOR

1шт.

7

3123842R1

PAWL

ROOF HATCH LOCK, UP TO ROOF 5861

1шт.

7

3129042R1

PAWL

ROOF HATCH LOCK, ROOF 5862 UP, INCLUDES: SCREWS

1шт.

27479R1

SELF-TAP SCREW,Cross Pan Hd, #6 x 1"

NO 6-32 X 1 PAN HD CR TAPPING

2шт.

8

3123085R91

DOOR

CPTE HATCH, UP TO ROOF 5861

1шт.

8

3129043R91

DOOR

CPTE HATCH, ROOF 5862 UP, CONSISTS ITEMS 6, 8-17 INCLUSIVE, INCLUDES: PINS AND CLIPS

1шт.

3123843R1

PIN

HINGE PIVOT

2шт.

3123844R1

RING

CLIP, RETAINING

4шт.

9

3123832R1

HANDLE

GRAB, INCLUDES: SCREWS, NUTS AND WASHERS

1шт.

712684R1

SCREW,Sltd Pan Hd, M5 x 10

M5 X 12 CHEESE HD

2шт.

934871R1

NUT,M5, Cl 5

M5

2шт.

934490R1

LOCK WASHER,Ext Tooth, M5

M5 TOOTH LOCK

2шт.

10

3123669R1

PROTECTION STRIP

EDGING

1шт.

11

3123836R1

BALL JOINT

GAS STRUT, INCLUDES: WASHER

1шт.

174916

LOCK WASHER,Ext-Int Tooth, 1/4"

1/4 TOOTH

1шт.

12

3123835R1

CYLINDER, GAS

STRUT

1шт.

13

3123840R1

SNAP RING

CLIP, RETAINING

1шт.

14

3123837R1

PIN

GAS STRUT PIVOT, INCLUDES: WASHER

1шт.

95-11028

WASHER,1/4"

625 X 281 X 061 PLAIN

1шт.

15

3123839R1

SPRING

1шт.

16

3123838R1

SPACER

GAS STRUT PIVOT PIN

1шт.

17

3123841R1

CLIP

RETAINING

1шт.

18

3123831R1

SEALING STRIP

SPARE PART EDGING HATCH

2шт.

19

3123827R2

INSULATOR

OUTER ROOF REAR

1шт.

20

3123826R1

INSULATOR

OUTER ROOF

2шт.

3123867R1

VISOR, SUN

NOT ILLUSTRATED

1шт.

3123868R1

SCREW

M55 X 25 FLAT HD CR, NOT ILLUSTRATED

2шт.
