Запчасти Case IH 884 (12-23) - COOLANT FILTER CONDITIONER Power

1

3228184R1

FLANGE

1шт.

179817

BOLT,Hex, 5/16" - 18 x 7/8", Gr 5, Full Thd

2шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

2

3055306R1

GASKET

flange

1шт.

3

606618C1

ELBOW UNION

ELBOW

1шт.

4

3228628R91

TUBE

water inlet

1шт.

3228191R1

SEALING WASHER

SLEEVE

2шт.

5

1801090C1

FILTER

coolant

1шт.

6

3228627R1

BRACKET

SUPPORT, coolant filter

1шт.

103026

NUT,3/8"-24, G5

2шт.

25534R1

WASHER

.406 x .812 x .065 phc hdn

2шт.

20285H

WASHER

.406 x .750 x .105 pln

2шт.

7

1800029C1

HEAD

SOCKET, coolant filter

1шт.

186285

BOLT,Hex, 3/8" - 16 x 4", Gr 5

2шт.

20534R1

BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 8

1/2 x 1-3/4 type 8

2шт.

8

121894C1

FAUCET,3/8" - 18 NPTF x 5/8" - 24

VALVE, shutoff replaces 690191C1

2шт.

9

3228671R91

TUBE

water outlet

1шт.

3228191R1

SEALING WASHER

SLEEVE

2шт.

10

3233208R1

UNION

1шт.
