Запчасти Case IH 884 (12-17) - COMPLETE SERVICE ENGINE Power

3228040R93

ENGINE

complete service, International 884 tractors with synchromesh drive and Bosch injection, consists of all engine parts except the following alternator-generator, belt, fan, blade, fan, muffler and exhaust pipe

1шт.

3218064R93

SKELETON ENGINE

ENGINE ASSY, skeleton service D-268, consists of camshaft w/gear and bearings, connecting rods w/bearings, crankcase assembly, crankshaft w/bearings, pistons w/pins and rings, skeleton engine

1шт.

3136799R99

GASKET KIT

PACKAGE, cylinder head gasket, consists of, service packages

1шт.

717203R1

O-RING,4mm Thk x 17mm ID, 72 Duro

injection nozzle, service packages

4шт.

3053133R1

SEALING RING,M8 x 11.5 x 1

RING, packing, service packages

8шт.

3138642R1

GASKET

valve housing cover, service packages

1шт.

3055398R1

GASKET

intake manifold, service packages

1шт.

3055306R1

GASKET

water collecting pipe, service packages

4шт.

3138638R1

RING,7.5mm ID x 15mm OD x 4mm Thk

disc valve housing cover, service packages

4шт.

3056941R1

SEALING WASHER,6.5mm ID x 12mm OD x 1mm Thk

RING, packing, service packages

4шт.

3132143R1

GASKET

water outlet thermostat, service packages

1шт.

3228362R1

CYLINDER HEAD GASKET

cylinder head, service packages

1шт.

3132434R1

MANIFOLD GASKET,0.5mm Thk

exhaust manifold, service packages

4шт.

3228677R91

SEAL

PACKAGE, valve stem seal, service packages

1шт.

3136813R99

GASKET KIT

PACKAGE, crankcase gasket, consists of, service packages

1шт.

172602

SUPPORT

expansion, service packages

1шт.

380839R1

O-RING,0.103" Thk x 0.862" ID, -118, Cl 6, 90 Duro

service packages

1шт.

710097R2

SEALING RING,14mm ID x 18mm OD x 1.5mm Thk

Packing, Service packages M14 x 18 x 1.5

1шт.

713778R1

O-RING,3mm Thk x 55mm ID

service packages

1шт.

714868R1

SEALING STRIP

seal, service packages

2шт.

717222R1

O-RING

Service packages

1шт.

933087R2

SEALING RING,10mm ID x 13.5mm OD x 1mm Thk

- Packing, Service packages M10 x 13.5 x 1

1шт.

933068R1

NUT,Thin, M24 x 1.5

RING, packing, service packages

1шт.

3138687R1

RING

packing, service packages

2шт.

3138640R1

GASKET

injection pump cover, service packages

1шт.

3055161R1

GASKET

oil pan, service packages

1шт.

3055177R1

GASKET

water pump, service packages

1шт.

3055215R1

GASKET

crankshaft, service packages

1шт.

3055237R1

GASKET

oil filter base, service packages

1шт.

3055239R1

GASKET

front plate, service packages

1шт.

3138639R1

GASKET

crankcase breather, service packages

1шт.

3055384R1

GASKET

fuel injection pump, service packages

1шт.

3055393R3

GASKET

side cover, service packages

1шт.

3055952R2

O-RING

RING, oil pump sealing, service packages

2шт.

3055961R1

GASKET

oil pump, service packages

1шт.

3055999R1

GASKET

water pump carrier, service packages

1шт.

3132541R1

GASKET

closing cover, service packages

1шт.

933610R1

SEALING RING,M14 x 18 x 1.8

Service packages M14 x 18 x 1.8

8шт.

713845R1

SEALING WASHER,M12 x 15.5 x 1.5

Packing, Service packages M12 x 15.5 x 1.5

3шт.

3055994R1

GASKET

cover, service packages

1шт.

3052295R91

SEAL,6mm ID x 16mm OD x 7mm Thk

SEAL, radial lip type oil, service packages

1шт.

784162R91

SEALING RING

SEAL, radial lip type oil, service packages

1шт.

3144697R1

GASKET

oil pan, service packages

1шт.

3228577R1

O-RING,3.1mm Thk x 24.5mm ID, Cl 7

service packages

9шт.

934005R1

SEALING RING,12mm ID x 18mm OD x 1.5mm Thk

Service packages M12 x 18 x 1.5

1шт.

3055389R2

O-RING,2.5mm Thk x 32mm ID, 70 Duro

service packages

1шт.

3132869R1

O-RING

service packages

1шт.

933155R1

SEALING RING,M16 x 20 x 1.5

Packing, Service packages M16 x 20 x 1.5

1шт.

3136406R1

GASKET

cover, service packages

1шт.

3136674R2

BLADE

PRODUCT-GRAPHIC

1шт.
