Артикул
Название
Примечание
Количество
1
380008R1
PLATE ASSY.
PLATE, stay rod ball socket cap lock
1шт.
2
379953R1
CAP
stay rod ball socket
1шт.
3
379954R1
SHIM
stay rod ball socket cap
1шт.
4
379952R1
SOCKET
stay rod ball
1шт.
271566
SUPPORT,Hex, 5/8" - 11 x 3", Gr 5
SCREW, 5/8-11 x 3 hex-hd cap
2шт.
5
10546D
BALL
stay rod
1шт.
6
379951R11
STAY ROD ASSY
1шт.
427546
JAM NUT,Jam, 1 3/8"-12, G5
1-3/8-12 hex. jam
2шт.
7
384435R92
ROD
ASSY, tie
2шт.
32-822
COTTER PIN,1/8" x 1 3/8"
Pin, Split (Cotter), 1/8" x 1 3/8"
4шт.
8
384005R92
JOINT
END ASSY, tie rod, LH thread
2шт.
9
358901R1
SLOTTED NUT
tie rod end
4шт.
10
387280R2
COVER
dust
4шт.
11
109461
LUBE NIPPLE,1/8"-27 x .66 lg
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg
4шт.
12
374062R1
JAM NUT
NUT, jam, LH thd
2шт.
13
384436R1
TUBE,0.948" ID, 1.187" OD, 14.562" Length
tie rod
2шт.
14
374061R1
JAM NUT
jam, RH thd
2шт.
15
384006R92
END
ASSY, tie rod, RH thread
2шт.
16
522246R1
HEADED PIN,19.05mm OD x 63.5mm L
PIN, 3/4 x 2-1/2 clevis
1шт.
NLS
NO LONGER SERVICED
1/4 x 1-1/8 cotter
1шт.
17
399972R1
BUSHING,25.44mm ID x 28.59mm OD x 28.83mm L
pivot pin
1шт.
18
399973R92
ARM
ASSY, center steering
1шт.
19
80722
LUBE NIPPLE,3/16" x .55" lg, Drive
FITTING, 3/16 drive type str lub, Serial Range: -9613
1шт.
19
109461
LUBE NIPPLE,1/8"-27 x .66 lg
NIPPLE, LUBE, , NPTF 1/8"-27 x .66 lg, Start Serial: 9614
1шт.
20
401768R92
STEERING KNUCKLE
KNUCKLE W/OIL SEAL, 370254R91 and shield, 48701D, steering
2шт.
427645
SLOTTED NUT,7/8"-14, G5
NUT, 7/8-14 slt hex.
2шт.
427546
JAM NUT,Jam, 1 3/8"-12, G5
1-3/8-12 hex. jam
2шт.
108643
COTTER PIN,5/32" x 1 3/8"
Pin, Split (Cotter), 5/32" x 1 3/8"
2шт.
Q326
WASHER
1-13/32 x 2-3/4 x 18 ga
2шт.
21
55412D
WASHER
WASHER, steering knuckle pivot felt
2шт.
22
357349R91
THRUST BEARING,42.53mm ID x 81.74mm OD x 19.18mm W
ASSY, steering knuckle pivot thrust
2шт.
23
358958R2
BUSHING,42.57mm ID x 46.08mm OD x 51.05mm L
steering knuckle pivot pin
4шт.
24
384001R12
AXLE, w/four bushings, 358958R2 and two bushings, 379943R1, front
1шт.
25
80722
LUBE NIPPLE,3/16" x .55" lg, Drive
FITTING, 3/16 drive type str lub, steering knuckle pivot pin
2шт.
26
146008R1
SNAP RING,M41.15 x 2.46mm Thk, Ext
RING, steering knuckle retaining
2шт.
27
384017R3
ARM
RH steering knuckle
1шт.
28
379943R1
BUSHING,38.11mm ID x 41.41mm OD x 38.1mm L
front axle pivot pin
2шт.
29
379941R1
AXLE PIN,38.1mm OD x 219.2mm L
PIN, front axle pivot
1шт.
30
219-45
LUBE NIPPLE,65 Degree Elbow, 1/4" NPTF
FITTING, 1/4 65 deg angle drive type lub
1шт.
31
399976R92
BRACKET
BOLSTER ASSY, lower
1шт.
U5360
AXLE PIN
PIN, 3/8 x 6-1/8 headed
1шт.
103384
COTTER PIN,1/8" x 3/4"
Pin, Split (Cotter), 1/8" x 3/4"
1шт.
20295R1
HEX SOC SCREW,5/8"-11 x 3"
SCREW, 5/8-11 x 3 hex-soc-hd cap
1шт.
20296R1
HEX SOC SCREW,5/8"-11 x 2"
5/8-11 x 2 hex-soc-hd cap
2шт.
32
399974R1
SHAFT
center arm pivot
1шт.
16006R1
BALL
3/16 cr-stl
1шт.
33
384016R3
ARM
LH steering knuckle
1шт.
34
389052R1
CLEVIS COUPLING
CLEVIS, cylinder end
1шт.
179845
BOLT,Hex, 3/8" - 16 x 1 3/4", Gr 5
SCREW, 3/8-16 x 1-3/4 hex-hd cap
1шт.
35
392991R1
SHIM
center arm pivot pin, .020
1шт.
35
392990R1
SHIM
center arm pivot pin, .010
1шт.
36
219-53
LUBE NIPPLE,65 Degree Elbow, 3/16" NPTF
FITTING, 3/16 65 deg angle drive type lub, Serial Range: -9613
1шт.
36
109461
LUBE NIPPLE,1/8"-27 x .66 lg
NIPPLE, LUBE, , NPTF 1/8"-27 x .66 lg, Start Serial: 9614
1шт.
Выбрано товаров: 54
