Артикул
Название
Примечание
Количество
1
A9596
SPARE PART
ARM - R.H. (w/straight spline), Serial Range: -8233547
1шт.
1
A24708
ARM - R.H. (w/taper spline), Start Serial: 8233547
1шт.
2
A9587
ARM - L.H. (w/straight spline), Serial Range: -8233547
1шт.
2
A24709
ARM - L.H. (w/taper spline), Start Serial: 8233547
1шт.
3
14-848
BOLT,Hex, 1/2" - 20 x 3", Gr 5
- arm to spindle, 1/2 x 3" N.F. hex
2шт.
4
92-8
LOCK WASHER,1/2"
2шт.
5
25-118
NUT,1/2"-20, G5
- 1/2" N.F. hex
2шт.
6
129-131
NUT,1 1/8"-12, G5
- 1-1/8" N.F. hex, Start Serial: 8233547
2шт.
7
A35047
WASHER
- (1-3/16 x 2-1/2 x 5/32"), Start Serial: 8233547
2шт.
8
25-2318
SLOTTED NUT,1 1/8"-12, G5, Thk
NUT - 1-1/8" N.F. slotted, Serial Range: -8233547
2шт.
9
132-97
COTTER PIN,3/16" x 1 3/4"
Pin, Split (Cotter), 3/16" x 1 3/4", Serial Range: -8233547
2шт.
10
T25078
WASHER - (1-3/16 x 2-9/16 x 3/16"), Serial Range: -8233547
2шт.
15
A24645
SHIM,.0149" Thk
, Start Serial: 8233547
1шт.
15
A24643
SHIM,.0359" Thk
, Start Serial: 8233547
1шт.
15
A24642
SHIM,.0598" Thk
, Start Serial: 8233547
1шт.
15
A24639
SHIM,.1345" Thk
, Start Serial: 8233547
1шт.
16
A7849
GUARD
SHIELD - dust, spindle bearing
2шт.
17
A27564
OIL SEAL
- oil, arm spindle
2шт.
18
A7851
NEEDLE BEARING,Needle, 38.09mm ID x 47.64mm OD x 25.4mm W
BEARING - needle, upper
2шт.
19
A28230
NEEDLE BEARING,Needle, 50.78mm ID x 60.34mm OD x 25.4mm W
BEARING - needle, lower
2шт.
20
A28231
X
WASHER - thrust, arm spindle
4шт.
21
A27602
THRUST BEARING,2.041" ID x 2.9475" OD x 0.635"
BEARING - thrust, arm spindle
2шт.
22
A7848
SPINDLE - strg. arm (w/str. spline), Serial Range: -8233547
2шт.
22
A24707
SPINDLE - strg. arm (w/tapered spline), Start Serial: 8233547
2шт.
23
A7850
SPINDLE - wheel
2шт.
24
126-144
WOODRUFF KEY,#129, 3/8" x 2 1/8", HT
KEY - spindle (Woodruff #129)
2шт.
25
129-131
NUT,1 1/8"-12, G5
- 1-1/8" N.F. hex
2шт.
26
T25078
WASHER - spindle nut (1-3/16 x 2-9/16 x 3/8")
2шт.
30
A7847
AXLE - extension (53"-82" thread)
2шт.
31
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease, 1/8" P.T. str.
3шт.
32
A7836
CLAMP - axle extension
4шт.
33
16-10112
BOLT - 5/8 x 7" N.F. hex
2шт.
34
14-1072
BOLT,Hex, 5/8" - 18 x 4-1/2", Gr 5
- 5/8 x 4-1/2" N.F. hex
4шт.
35
25-1110
NUT,5/8"-18, G5
- 5/8" N.F. hex
6шт.
37
A7835
AXLE ASSY. - center section (53" - 82" thread) (incl. ref. 38 & 39)
1шт.
38
F62008
BUSHING
- pivot, axle rear
1шт.
39
A7841
BUSHING,31.75mm ID x 38.18mm OD x 38.35mm L
- pivot, axle frt. (1-1/4 x 1-1/4 x 1-1/2")
2шт.
40
A7837
PEDESTAL - front axle
1шт.
41
13-1028
BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 5, Full Thd
4шт.
43
A7840
PIVOT PIN
PIN - pivot, front
1шт.
44
13-612
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
1шт.
45
92-6
LOCK WASHER,3/8"
1шт.
46
219-55
LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF
NIPPLE, LUBE, 90º, 1/8" NPT x .84" lg
1шт.
47
B18131
WASHER,32.16mm ID x 55.63mm OD x 3.17mm Thk
- thrust, pivot pin
2шт.
48
A8745
ARM - center (Order A23132), Serial Range: -8173401
1шт.
48
A23132
ARM - steering, center, Start Serial: 8173401
1шт.
49
14-1024
BOLT,Hex, 5/8" - 18 x 1-1/2", Gr 5
4шт.
50
193-14
LOCK WASHER,Ext Tooth, 5/8"
WASHER, LOCK, Ext Tooth, 5/8"
4шт.
51
A7845
SUPPORT - rear, radius rod
1шт.
52
13-1028
BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 5, Full Thd
2шт.
54
A7843
PIN
- pivot, radius rod
1шт.
55
A26949
RING, SNAP
RING - snap, pivot pin
2шт.
Выбрано товаров: 55
