Артикул
Название
Примечание
Количество
1
3118502R92
CYLINDER
ASSY, power steering
1шт.
536314R92
SERVICE KIT
KIT, o-ring and seal service, see parts catalog cyl-1 for service parts
1шт.
2
518505R1
HEADED PIN,3/4" x 3"
PIN, power steering cylinder
1шт.
3
9410202
HYD CONNECTOR,9/16"-18, 37 Degree x 9/16"-18, O-Ring
CONNECTOR, 3/8 C-Z hyd fld short swivel
1шт.
4
9410254
ELBOW,45 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree Fem Sw
3/8 C-Z hyd fld 45D swivel
1шт.
5
9410976
ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring
3/8 C-Z hyd fld adj 90D
1шт.
6
3121235R1
HOSE
power steering cylinder
2шт.
7
9403293
LOCK NUT,Blkhd, 9/16"-18
NUT, 3/8 C-Z bulkhead union lock
2шт.
8
9403254
FITTING,Blkhd, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree
UNION, 3/8 C-Z hyd fld tube bulkhead
2шт.
120898
LOCK WASHER,9/16"
WASHER, LOCK, 9/16"
2шт.
9
529646R1
BRACKET
front manifold support
1шт.
9635082
NUT,5/16" - 18, Gr 5
1шт.
10
3125265R1
PIPE,9.53 mm OD, 1051.1, 654.5 mm Length
TUBE ASSY, power steering RH forward
1шт.
11
384891R11
CLAMP
ASSY, power steering tube
1шт.
179795
TILLAGE BLADE
1/4 x 3/4 pln type 5
1шт.
103319
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
1шт.
12
529642R1
BRACKET
front manifold
1шт.
109084
NUT,1/4"-20, G5
1шт.
103319
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
1шт.
13
3125264R1
TUBE ASSY.,9.53 mm OD, 1051.1, 654.5 mm Length
TUBE ASSY, power steering LH forward
1шт.
14
529644R11
CLAMP
ASSY, power steering tube
1шт.
NLS
NO LONGER SERVICED
1/4 x 7/8 pln type 5
1шт.
103319
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
1шт.
95-11028
WASHER,1/4"
.281 x .625 x .051 pln
1шт.
15
3116268R3
TUBE ASSY.
TUBE ASSY, power steering RH rear
1шт.
16
3116267R1
TUBE ASSY.
TUBE ASSY, power steering LH rear
1шт.
17
3116272R2
TUBE ASSY.
TUBE ASSY, power steering return forward
1шт.
18
3116271R2
TUBE ASSY.,0.375" OD, 12.44, 4.28" Length
TUBE ASSY, power steering pressure forward
1шт.
19
587639R1
HYD CONNECTOR,9/16"-18, 37 Degree x 3/4"-18, O-Ring
CONNECTOR, C-Z hyd fld 1/2 to 3/8 sht
4шт.
21
VALVE ASSY, integral power steering, for components see list of parts under details of integral hydrostatic valve
1шт.
22
306132C1
CABLE TIE,14.5" L
STRAP, rear mainfold tubes
2шт.
23
529638R1
BRACKET
rear mainfold
1шт.
24
529637R2
GUIDE
manifold tube
1шт.
25
1502293C1
TUBE
ASSY, power steering pressure rear
1шт.
26
536009R1
FUEL HOSE,0.31" ID x 2.50"
Spacer 0.31" ID x 2.50"
2шт.
27
3129257R1
TUBE ASSY.
TUBE ASSY, power steering return rear
1шт.
28
3121187R91
SHAFT
steering w/nut
1шт.
660200R1
SPACER,10.7mm ID x 17.14mm OD x 9.5mm L
includes bolts
2шт.
179835
BOLT,Hex, 3/8" - 16 x 5/8", Gr 5, Full Thd
4шт.
29
F19646
LOCK NUT,13/16"-20, Thin
NUT, steering shaft hex
1шт.
30
3129261R1
BRACKET
tube retaining
1шт.
31
57577C1
CHECK VALVE
VALVE ASSY, check
1шт.
32
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
6-1, 90 Duro, .468" ID x .078" Thk, 3/8 OD tube, class 6
3шт.
Выбрано товаров: 45
